Portable Double-Tank Automatic CIP Cleaning Unit System
This portable double-tank CIP unit prepares and circulates wash and rinse solutions through process lines, tanks, valves, and fillers. Stainless construction, pump and return options, heating, and manual to PLC controls are configured to the duty. Send your piping details, cleaning capacity, heat source, and automation needs for a factory-direct recommendation and quotation.
- Tank Capacity: [100L–5000L or specify actual capacity]
- CIP Types:Single-tank cleaning, two-tank system, three-tank system, four-tank system.
- Material: SUS304 / SUS316L
- Optional configurations: [trolley, mixer, PLC control, manual control]
- Surface Finish: [2B / Brushed / Polished / Mirror Polish]
- If you have drawings, we can process them for you.
Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909
Price range: $6,993.13 through $8,891.76
Guaranteed Safe Checkout
A portable double-tank CIP unit gives a plant flexible cleaning capacity without a fixed utility room. It prepares and circulates cleaning solution through tanks, lines, fillers, valves, and process equipment, then returns it for reuse or drain. A typical cycle covers pre-rinse, caustic wash, intermediate rinse, acid wash if needed, and final rinse. Temperature, flow, pressure, and level are the variables that decide whether the circuit actually cleans.
We build the skid in stainless steel with two cleaning tanks, supply and return pumps as required, and piping sized to your circuit. Final scope follows the confirmed duty, not a catalog default.
Configuration choices
Project options include single-, double-, or multi-tank layouts; acid, caustic, and hot-water tanks; electric or steam heating; manual, semi-automatic, or PLC control; and temperature, flow, pressure, and level monitoring. Tank volume, pump duty, circuits, and dimensions can be customized. These are options, not standard on every unit; the quotation lists confirmed features.
How to size it
Start with tank volume, pipe diameter and total line length, valve count, spray devices, soil type, and rinse water quality. Dairy milk stone and brewery soil need different chemistry and temperature. Oversizing the pump can hurt spray performance; undersizing it leaves dead legs. Send a P&ID or line list, and we can recommend tank volume, pump flow, heating load, and control level.
Typical specifications
Typical shop data; confirm details on the quotation.
| Item | Typical range |
|---|---|
| Cleaning tank capacity | 50–500 L per tank, custom |
| Number of tanks | 2 standard; 1, 3, 4 optional |
| Stainless grade | 304 or 316L |
| Heating | Electric or steam |
| Pump flow and pressure | 5–30 m³/h; 2–6 bar |
| Working temperature | Ambient to 80°C |
| Controls | Manual, semi-auto, or PLC |
| Cleaning circuits | 1–4 or custom |
| Power | 220/380/415 V, 50/60 Hz |
| Dimensions | Skid and tanks sized to layout |
| Custom options | Tank volume, circuits, automation |
Applications
Dairy processors, beverage and brewery lines, distilleries, sauce and liquid-food plants, cosmetics, and pharmaceutical process equipment use CIP skids like this. Cleaning requirements vary by product residue; confirm chemistry, temperature, and rinse regime against your own sanitation program.
FAQ
Can it clean multiple circuits? Yes, with confirmed valve and piping arrangement. Do we need steam? Electric heating works for smaller tanks; steam suits larger volumes. What controls? Manual, semi-auto, or PLC, depending on recipe and record needs. What do you need for a quote? Application, tank and pipe details, cleaning capacity, heat source, automation level, stainless grade, and install location.
Tell us your industry, product, tank and piping details, required cleaning capacity, heat source, automation level, stainless grade, and installation requirements. We will recommend the tank configuration, pump duty, heating, and controls, then provide a factory-direct quotation.
