Split-Type Fully Automatic CIP System for Tanks and Pipelines
Split-type automatic CIP systems separate solution tanks from the circulation skid, making them easier to fit where floor space is limited. We build stainless steel acid, alkaline and hot-water cleaning packages with matched pumps, valves, heating and PLC monitoring for tanks, pipelines, fillers and process equipment. Tell us your circuits and cleaning duty for a factory-direct configuration.
- Tank Capacity: [100L–5000L or specify actual capacity]
- CIP Types:Single-tank cleaning, two-tank system, three-tank system, four-tank system.
- Material: SUS304 / SUS316L
- Optional configurations: [trolley, mixer, PLC control, manual control]
- Surface Finish: [2B / Brushed / Polished / Mirror Polish]
- If you have drawings, we can process them for you.
Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909
Price range: $7,736.50 through $9,311.65
Guaranteed Safe Checkout
How a Split-Type CIP System Fits Your Plant
Our split-type fully automatic CIP system separates solution tanks from the circulation skid. That layout helps when floor space is tight or wash points sit far apart. Tanks, pumps, heat exchanger, valves and instrumentation are fabricated in stainless steel and matched to the cleaning loop. We build single-, double-, triple- and multi-tank arrangements, with dedicated acid, alkaline and hot-water tanks as required.
A cleaning cycle typically runs pre-rinse, alkaline wash, intermediate rinse, acid wash, final rinse and sanitizing if specified. Temperature, flow, pressure, conductivity and level signals are monitored; PLC control logs step times and alarms. The system can clean fermenters, process tanks, mixers, fillers, pasteurizers, transfer lines, valves, pumps and heat exchangers. Capacity, pump head and tank volume should follow the largest circuit and soil load, not just total plant volume.
Typical Configuration Choices
- Single-, two-, three- or multi-tank CIP skids
- Acid and caustic solution tanks, optional hot-water tank
- Electric or steam heating
- CIP supply and return pumps
- Stainless piping, valves and fittings
- Temperature, flow, pressure and level monitoring
- Manual, semi-automatic or PLC operation
- Custom tank capacity and wash circuits
These are available options, not a standard package. Final configuration depends on your circuits, soil type, water quality and automation needs.
Technical Specifications
| Cleaning tank capacity | Custom, typically 500–10,000 L per tank; confirm per project |
|---|---|
| Number of tanks | 1–4+ including acid, alkali, hot water or recovery |
| Stainless grade | 304 or 316L wetted parts |
| Heating | Electric or steam |
| Pump flow and pressure | Sized to circuit; example 10–100 m³/h at 3–6 bar |
| Operating temperature | Up to 80–90°C depending on chemistry and design |
| Control system | Manual, semi-automatic or PLC/HMI |
| Cleaning circuits | Single or multiple with supply and return manifolds |
| Power | 380/415/440 V, 3 phase, 50/60 Hz, market dependent |
| Dimensions | Custom skid; depends on tank volume and layout |
| Custom options | Insulation, conductivity, data logging, extra wash points |
Where It Is Used
Dairy, beverage, brewery, distillery, sauce, liquid food, cosmetics and pharmaceutical plants use CIP to repeat wash cycles without dismantling lines. Cleaning requirements vary by residue and material; we review wetted parts, temperature limits and drainage before quoting.
FAQ
How do I choose tank count? Count separate chemistries and rinse stages. Two tanks often suit acid/alkali; three add hot water or recovery.
Can we add wash points later? Yes, if valve manifolds and pump capacity allow. Tell us future circuits early.
What information speeds a quote? Tank and pipe sizes, soil type, wash points, heat source, stainless grade, automation level and site utilities.
Request a Configuration Review
Send your industry, product, tank and pipeline details, required cleaning capacity, heat source, automation level, stainless grade and installation location. Our engineers will recommend tank volume, pump duty and controls, then provide a factory-direct quotation.
