Explosion-Proof Electric CIP Cart | Stainless Steel Cleaning System
This electric CIP cart pairs an explosion-proof pump with stainless steel construction for cleaning tanks, lines, and process equipment. Choose single- or multi-tank layouts, electric or steam heat, and manual to PLC control. We build each unit to your circuit count, cleaning capacity, and plant requirements, with engineering support from configuration through commissioning.
- Tank Capacity: [100L–5000L or specify actual capacity]
- CIP Types:Single-tank cleaning, two-tank system, three-tank system, four-tank system.
- Material: SUS304 / SUS316L
- Optional configurations: [trolley, mixer, PLC control, manual control]
- Surface Finish: [2B / Brushed / Polished / Mirror Polish]
- If you have drawings, we can process them for you.
Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909
Price range: $7,414.94 through $8,910.53
Guaranteed Safe Checkout
Mobile CIP for Isolated Tanks and Lines
A fixed CIP skid does not fit every layout. This electric CIP truck puts a cleaning tank, pump set, and controls on a stainless frame so one unit can serve isolated tanks, filler lines, and transfer piping. Explosion-proof pump and control arrangements are available where the site classification requires them. Final rating depends on area classification, wiring, and component selection; we confirm that during engineering.
Cleaning Cycle and Configuration
Typical cycles run pre-rinse, caustic wash, intermediate rinse, acid wash when needed, and final rinse. Supply and return pumps move solution through tanks, lines, valves, and spray devices. Monitoring options include temperature, flow, pressure, and tank level. Available layouts include single, double, triple, or multi-tank systems; separate caustic, acid, and hot-water tanks; electric or steam heating; manual, semi-automatic, or PLC/HMI control; and stainless piping, valves, and fittings. These are project-specific choices, not standard on every cart.
Typical Specifications
| Item | Range or Option |
|---|---|
| Cleaning tank capacity | Project-specific, commonly 100 to 2,000 L |
| Number of tanks | 1 to 4 or more, by rinse and acid/caustic separation |
| Stainless grade | 304 or 316L wetted parts; 304 frame |
| Heating method | Electric immersion or steam |
| Pump flow and pressure | Sized to circuit volume and pressure drop |
| Operating temperature | Set by cleaning recipe |
| Control system | Manual, semi-automatic, or PLC/HMI |
| Cleaning circuits | One or more supply/return circuits |
| Power | Customer voltage and frequency; explosion-proof components where specified |
| Dimensions | Built around tank size, pump set, and cart frame |
| Custom options | Tank volume, circuits, automation, and material certificates |
Where These Carts Fit
Dairy, beverage, brewery, distillery, sauce, liquid food, cosmetics, and pharmaceutical plants use mobile CIP where circuits change or space is tight. Soil type, surface finish, pipe diameter, dead legs, and rinse volume drive the cleaning recipe and tank count.
FAQ
How much tank capacity do I need? Start with rinse volume per circuit and washes per shift. Long runs and multiple circuits usually need more solution and a stronger return pump.
Can we add tanks later? Sometimes, but frame space, valves, and controls should be planned up front.
Does an explosion-proof motor make the cart explosion-proof? No. The motor, controls, wiring, and enclosure must match the classified area.
Get a Quote
Send your industry and processed product, tank and piping details, required cleaning capacity, heat source, automation level, stainless grade, and installation location. We will recommend the tank configuration, pump set, and control scope, then provide a factory-direct quotation with engineering support.
