CIP Cleaning System for Tea, Beverage & Milk Production Lines
Factory-direct CIP cleaning systems for tea drinks, beverage, milk and liquid food lines. We build single- or multi-tank skids with stainless piping, electric or steam heating, supply/return pumps and PLC monitoring. Share your tank volume, piping layout and cleaning capacity so we can recommend the right wash cycle and configuration.
- Tank Capacity: [100L–5000L or specify actual capacity]
- CIP Types:Single-tank cleaning, two-tank system, three-tank system, four-tank system.
- Material: SUS304 / SUS316L
- Optional configurations: [trolley, mixer, PLC control, manual control]
- Surface Finish: [2B / Brushed / Polished / Mirror Polish]
- If you have drawings, we can process them for you.
Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909
Price range: $6,998.97 through $8,915.29
Guaranteed Safe Checkout
CIP Systems for Tea, Beverage and Milk Lines
We manufacture CIP cleaning systems for tea drinks, beverage, milk and liquid food lines, plus restaurant and food-shop wash areas. The skid circulates detergent, rinse water and sanitizer through tanks, piping, fillers, mixers and process loops. A correctly sized system gives repeatable cycles and less water and chemical waste than manual wash-down.
A typical cycle runs pre-rinse, alkaline wash, intermediate rinse, acid wash if needed, final rinse and sanitizing. We size pump flow against line volume and return-line pressure drop, not tank volume alone. Dead legs and poor drain slope cause many weak CIP results.
Configuration Options
Available configurations include single-, double-, triple- or multi-tank systems; caustic and acid tanks; hot-water tanks; electric or steam heating; supply and return pumps; stainless piping, valves and fittings; and manual, semi-automatic or PLC control. Tank size, wash circuits and automation can be customized after review. Confirm features for your project before ordering.
| Technical Item | Typical Range |
|---|---|
| Cleaning tank capacity | Custom, typically 100–5,000 L per tank |
| Number of tanks | 1 to 4 or more |
| Stainless grade | 304 or 316L |
| Heating | Electric or steam |
| Pump flow and pressure | Selected for circuit volume and pressure drop |
| Operating temperature | Ambient to 80°C, project-dependent |
| Control | Manual, semi-automatic or PLC |
| Cleaning circuits | Single or multiple loops |
| Power supply | Customer-country specific |
| Dimensions | Skid-mounted, layout-dependent |
| Customization | Tank size, piping, automation and documentation |
Where CIP Fits
Applications include dairy processing, beverage production, breweries, distilleries, sauce manufacturing, liquid food processing, cosmetics and pharmaceutical production. Residue, chemistry, temperature and documentation needs vary, so we match stainless grade, finish and controls to the process.
Buyer Questions
How do I choose tank count? Count wash steps and chemistry changes. Simple rinse-sanitize cycles may use one tank; acid and caustic steps usually need separate tanks.
What determines pump size? Line volume, pipe diameter, return pressure drop and required flow velocity. A piping sketch helps.
Can we add PLC monitoring? Yes. We can quote temperature, flow, pressure and level monitoring with recipe control, depending on scope.
We build factory-direct stainless CIP systems with engineering support for layout, pumps, heat source and controls. Send your industry, processed product, tank and piping details, required cleaning capacity, heat source, automation level, stainless grade and installation location. We will recommend a practical configuration and quote.
