300L Stainless Steel Dual-Tank Movable CIP System with Pump and Washer
Built for plant teams that need a movable cleaning loop, this 300L stainless steel dual-tank CIP unit combines tanks, pump, piping, and tank washers on one frame. We size heating, pump flow, controls, and tank split around your circuits, then fabricate in-house. Send tank and pipe details for a firm configuration and quote.
- Tank Capacity: [100L–5000L or specify actual capacity]
- CIP Types:Single-tank cleaning, two-tank system, three-tank system, four-tank system.
- Material: SUS304 / SUS316L
- Optional configurations: [trolley, mixer, PLC control, manual control]
- Surface Finish: [2B / Brushed / Polished / Mirror Polish]
- If you have drawings, we can process them for you.
Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909
Price range: $6,091.57 through $7,496.29
Guaranteed Safe Checkout
What this movable dual-tank CIP unit is built to do
A CIP system is a controlled cleaning loop. It sends detergent, rinse water, and optional sanitizer through tanks, lines, valves, fillers, and process equipment at a set flow, temperature, and contact time. The return path matters as much as the supply line. If the pump is oversized or the return is restricted, the circuit will not clean evenly.
This 300 L nominal unit uses two stainless tanks on a movable frame. One tank can run alkaline wash while the other holds acid, rinse water, or recovery solution, depending on the circuit design. The pump, tank washers, and piping are arranged for food, beverage, dairy, sauce, cosmetic, and pharmaceutical cleaning duties. We confirm tank split, pump curve, heating, and controls against your actual circuit before fabrication.
Configuration choices
- Two tanks standard for this model; single, three, or multi-tank layouts available for other projects.
- Caustic and acid tanks, hot water tank, and recovery or rinse options.
- Electric or steam heating, sized to volume, starting temperature, and required ramp time.
- CIP supply and return pumps, stainless piping, valves, and fittings.
- Temperature, flow, pressure, and level monitoring; manual, semi-automatic, or PLC control.
These are configurable options, not automatic standard features. Final scope is fixed per project.
Technical specifications
| Cleaning tank capacity | 300 L nominal; per-tank working volume confirmed at order |
|---|---|
| Number of cleaning tanks | 2 |
| Stainless steel grade | 304 standard; 316L optional |
| Heating method | Electric or steam, project-specific |
| Pump flow and pressure | Sized to circuit; confirm at quotation |
| Operating temperature | Typically 60–80°C; set by cleaning chemistry |
| Control system | Manual, semi-automatic, or PLC/HMI |
| Cleaning circuits | Single or multiple supply and return paths |
| Power supply | Site-specific |
| Dimensions | Based on tank layout and frame |
| Custom options | Tank size, heating, pumps, instrumentation, skid layout |
Where it fits
Dairy lines, beverage and brewery vessels, winery tanks, sauce and liquid-food circuits, cosmetic mixing equipment, and pharmaceutical process lines use CIP routines. Cleaning requirements differ by residue, surface finish, pipe diameter, and validated procedures. We do not treat one CIP recipe as universal.
Selection points buyers often miss
Start with the largest and dirtiest circuit, not the smallest. Confirm return-line slope, drain points, dead legs, and pump suction conditions. Check available steam or electrical capacity. Decide whether operators will change recipes at the panel or through PLC recipes.
FAQ
Can the tanks be split for different chemistries? Yes, with specified tank linings, labels, and valve routing.
Is 300 L enough? It depends on circuit volume, dilution, and required contact time. Send line lengths and vessel sizes.
Can we add a third tank later? Usually not on the same frame without redesign. Plan tank count early.
Tell us your industry, processed product, tank and pipe details, required cleaning capacity, heat source, automation level, stainless grade, and installation location. We will recommend the tank split, pump size, heating load, and control scope, then quote from our factory.
