High Shear Dispersing Homogenizer for Powder & Liquid Pneumatic Mixer
- Material: 304 or 316L
- Voltage: 110V 208V 220V 380V 400V 415V 480V 600V
- Certificates: CE, GMP, UL, ATEX, ISO 9001
- Power：0.75KW-55KW （1 HP – 74 HP）
- Motor brands: ABB, Chinese brands, SEW, Siemens (optional)
- 1-year free warranty with door-to-door delivery.
- Optional: Variable-frequency drive, control panel
- MADE IN CHINA
- We have it in stock.
Please contact our sales team before placing your order.
Email:info@ace-chn.com
Tel:+86 18626835909
WeChat: ace-chn
Price range: $886.11 through $947.87
Guaranteed Safe Checkout
We manufacture and sell the following types of mixers
Mix, emulsify, homogenize, disintegrate and dissolve
Ideal for disintegrating solids and incorporating powders
Reduce mixing times by up to 80%
Reduce mixing times by up to 90%
Quickly disperse and hydrate powders, even at higher viscosities
Easy to move and lift
Features heating, cooling, vacuum, and other functions
Recommended RPM: 1480/2850 RPM
Powder wetting is where plenty of batches go wrong. The powder floats, forms lumps, or takes longer to dissolve than the schedule allows. Our movable high shear dispersing homogenizer is aimed squarely at that stage: the shear head pulls powder into the liquid and breaks down agglomerates before they cause trouble downstream.
On a mobile frame, one unit can serve several tanks in the same room. In plants running several small and mid-size batches per shift, that usually beats dedicating a drive to every vessel.
Configurations we build
- Speed control: optional VFD, adjustable from 0 to 3000 rpm depending on motor and configuration
- Motor power: 1.5 kW to 55 kW, selected against batch size and product viscosity
- Voltage: 220V to 480V, with frequency and phase confirmed for the destination market
- Wetted parts: 304 or 316L stainless steel, specified per product chemistry
- Function: high shear, dispersing, emulsifying, and powder-into-liquid incorporation
- Frame: movable or fixed, depending on how the room and tank layout actually works
What to work out before requesting a quote
Batch volume and tank geometry come first, since a head sized for 200 L behaves differently in a 2,000 L vessel. Then viscosity and solids loading, because those set the motor power and the shear head design. Electrical supply matters more than buyers expect; a 50 Hz service at three-phase 380V will not take the same drive as a 60 Hz 460V installation. Tell us the contact materials the product demands, and whether the unit stays on one tank or moves between several.
Where these units run
Food and beverage plants use them for stabilizers, gums, and concentrates. Cosmetic and personal care production relies on them for creams, gels, and pigment dispersion. Pharmaceutical and healthcare preparation, chemical processing, and paint and coatings manufacturing all involve similar powder dispersion or liquid-liquid emulsification steps. The right shear head, material, and operating parameters always come back to viscosity, formulation, and process requirement.
FAQ
Can one unit serve several tanks? Yes. The movable frame exists for that, though hose routing and floor clearance need checking first.
Is the VFD necessary? Not always. It earns its place when several formulations run at different speeds in the same machine.
How do we confirm voltage? Send the local supply, including voltage, frequency, and phase, and we configure the electrical package to match.
For a useful recommendation rather than a generic quote, send your batch size, product viscosity and composition, target rpm, required motor power, and local electrical specifications. Ace Mixer builds to the application, not to a catalog page.
A movable high shear dispersing homogenizer for powder incorporation and liquid-liquid emulsification in batch production. Motor power runs from 1.5 kW to 55 kW with optional VFD speed control to 3000 rpm, 304 or 316L wetted parts, and electrical packages built to your local supply. Configurable for food, cosmetic, pharmaceutical, chemical, and coatings batches.
