7.5kW 380V Inline High Shear Emulsifier Pump with VFD Control Box
- Material: 304 or 316L
- Voltage: 110V 208V 220V 380V 400V 415V 480V 600V
- Certificates: CE, GMP, UL, ATEX, ISO 9001
- Power：0.75KW-55KW （1 HP – 74 HP）
- Motor brands: ABB, Chinese brands, SEW, Siemens (optional)
- 1-year free warranty with door-to-door delivery.
- Optional: Variable-frequency drive, control panel
- MADE IN CHINA
- We have it in stock.
Please contact our sales team before placing your order.
Email:info@ace-chn.com
Tel:+86 18626835909
WeChat: ace-chn
Price range: $1,665.28 through $1,781.85
Guaranteed Safe Checkout
We manufacture and sell the following types of mixers
Mix, emulsify, homogenize, disintegrate and dissolve
Ideal for disintegrating solids and incorporating powders
Reduce mixing times by up to 80%
Reduce mixing times by up to 90%
Quickly disperse and hydrate powders, even at higher viscosities
Easy to move and lift
Features heating, cooling, vacuum, and other functions
Recommended RPM: 1480/2850 RPM
7.5 kW Inline High Shear Emulsifier Pump for Shampoo and Liquid Processing
This 7.5 kW high shear three-layer emulsifier pump is built for production lines that need faster wetting, better dispersion, and repeatable emulsions without tying up a batch tank. The rotor-stator head runs at high tip speed inside a compact housing. Product enters, passes through the shear zone, and exits as a more uniform stream. Install it inline on a pipe run or set it up as a recirculation loop on an existing tank. The 380 V, 50 Hz, three-phase motor is paired with a frequency inverter control box, so operators can tune speed to the formula instead of running flat out.
On shampoo, conditioner, lotions, and liquid detergents, the pump helps break down gum and polymer clusters and blend oil and water phases closer to the target droplet size. For sauces, syrups, dairy mixes, and beverage concentrates, it speeds powder wetting and reduces lumps that later clog filters or slow filling. We use stainless-steel contact parts for normal washdown and cleaning routines; seals, connections, and motor options can be changed for different viscosities and CIP needs. A three-layer shear head gives more residence time in the rotor-stator zone, which matters when your product needs a tighter emulsion but your tank has limited agitation.
Do not size the pump from motor kW alone. Flow rate, viscosity, solids loading, discharge pressure, and whether you run batch recirculation or continuous duty all affect the final configuration. Send us your batch size, ingredient list, target particle or droplet size if known, and local voltage. Our engineers will recommend the rotor-stator style, seal arrangement, port connections, and VFD settings for your line, then quote the correct 7.5 kW or alternative model.
Applications
- Shampoos, conditioners, creams, lotions, and liquid detergents
- Sauces, dressings, mayonnaise, syrups, and flavor concentrates
- Dairy blends, beverage ingredients, starches, gums, and stabilizers
- Liquid pharmaceutical dispersions and compatible chemical emulsions
FAQ
Can it run on my existing tank? Yes, as a recirculation loop, provided the pipework, valves, and tank outlet are sized for the pump flow.
Is 7.5 kW enough? It depends on viscosity, flow, and solids. We check duty point before quoting.
Can I change speed during a batch? The inverter control box allows speed adjustment; record settings by formula for consistency.
Ready to specify? Send batch size, material viscosity, desired motor power, and electrical supply to Ace Mixer for a firm recommendation and quote.
7.5 kW inline high shear emulsifier pump with 380 V, 50 Hz three-phase motor and frequency inverter control box. Built for shampoo, creams, sauces, and chemical emulsions, it improves powder wetting, dispersion, and recirculation-loop mixing. Contact Ace Mixer with batch size, viscosity, and electrical details for configuration and quote.
Single-stage in-line mixer
Three-stage in-line mixer
High-Shear Mixer with lift
High shear mixer
