1000L SUS316L Emulsion Mixing Tank with Steam Jacket and ABB Motor
A 1000L SUS316L emulsion and lotion mixing tank with steam jacket heating and an ABB motor for controlled batch processing. The final agitator, gearbox, seals, finish, controls, and connection layout are configured according to viscosity, heating requirements, cleaning procedures, and production conditions.
- Capacity: 50 liters to 30,000 liters
- Mixer power: 1.5 kW to 55 kW
- Material: [SUS304 / SUS316L]
- Voltage: 110V / 220V / 380V / 400V / 440V / 480V / 600V
- Heating method: [Electric / Steam / Thermal Oil / Hot Water / No Heating]
- Cooling method: [Cooling Jacket / Dimple Jacket / Coil / No Cooling]
- Agitation system: [Top Entry Agitator / Anchor Mixer / Paddle / Turbine / High-Shear Mixer / Customized]
- Optional features: [Insulation / Load Cells / Temperature Sensor / Pressure Gauge / Manhole / CIP / PLC Control / Explosion-Proof Motor]
- Certificates: ASME, CE, GMP, UL, ATEX, ISO 9001
- Working pressure: [Atmospheric / Positive Pressure / Vacuum / Specify pressure]
- If you have drawings, we can process them for you.
Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909
Price range: $2,287.20 through $2,705.53
Guaranteed Safe Checkout
Recommend RPM: 0-960RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing
Recommend RPM: 0-200RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing
Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For single wall tank
Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For jacket tank
Recommend RPM: 1480/2850 RPM
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion
Recommend RPM: 2800 - 3200 RPM
Viscosity: Low/medium/High viscosity
Application: Liquid powder mixing and homogenizing
Recommend RPM: 0-355RPM
Viscosity: Low/medium viscosity
Application: Install at bottom, No mechanical seal working condition
Recommend RPM: As above
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion For tank volume >300L
1000L SUS316L Emulsion Mixing Tank for Controlled Batch Processing
This 1000L mixing tank is intended for batch production where lotion, emulsion, cream, or similar viscous products require controlled agitation and indirect heating. The SUS316L product-contact construction is suited to formulations exposed to water, salts, active ingredients, or cleaning chemicals. We size the working volume, headspace, agitator, and heating duty around the actual batch recipe rather than treating 1000L as a universal operating volume.
Construction and Fabrication
The vessel is fabricated from SUS316L stainless steel in product-contact areas. Weld design, internal corners, drainability, and surface finish should be confirmed against the plant hygiene standard and cleaning method. Orbital or sanitary welding may be specified where required. Internal polishing, surface roughness, manway arrangement, spray devices, sampling ports, and mechanical seals depend on viscosity, solids content, cleaning chemicals, and the required cleaning procedure. The steam jacket provides indirect heat transfer, reducing direct-contact contamination risk; jacket pressure, steam quality, condensate removal, insulation, and temperature control must be defined before fabrication.
Agitation and Drive Selection
An ABB motor is specified as the drive motor, while the gearbox, speed range, shaft diameter, seal arrangement, and impeller geometry require process confirmation. Low-shear propeller, anchor, gate, or scraper-style agitation may suit different viscosities. Emulsion quality can depend more on shear location and circulation pattern than on motor power alone. A bottom homogenizer or high-shear head should not be assumed without laboratory or production data.
Technical Specifications
| Item | Provided information |
|---|---|
| Nominal capacity | 1000 L |
| Product-contact material | SUS316L |
| Heating method | Steam jacket |
| Drive motor | ABB motor |
| Agitation | Configured to product rheology and batch requirements |
Typical Uses
Common applications include cosmetic lotions, creams, pharmaceutical suspensions, personal-care emulsions, specialty chemicals, and selected food products. The final configuration should reflect sanitation requirements, flammability classification, vacuum operation, and cleaning method.
FAQ
Can the tank process high-viscosity lotion? Yes, subject to confirmation of viscosity, yield stress, solids, and required mixing time. These factors determine the agitator and gearbox.
What should accompany a quotation request? Send batch size, minimum and maximum fill levels, formulation viscosity, density, temperature range, heating time, steam conditions, cleaning method, electrical standard, and required connections.
How is the correct configuration selected? Our engineers review the process data, operating volume, sanitation expectations, and installation limits before recommending vessel geometry, agitation, seals, controls, and optional homogenization.
