1000L Jacketed Melting Tank for Chocolate, Fat, Wax, and Yogurt
This 1000L double-jacketed melting tank is designed for controlled heating and agitation of chocolate, edible fats, wax, yogurt bases, and selected chemical products. Jacket medium, stainless steel grade, agitator, drive torque, seals, finish, and temperature controls are configured around viscosity, batch size, heating time, sanitation requirements, and plant utilities.
- Capacity: 50 liters to 30,000 liters
- Mixer power: 1.5 kW to 55 kW
- Material: [SUS304 / SUS316L]
- Voltage: 110V / 220V / 380V / 400V / 440V / 480V / 600V
- Heating method: [Electric / Steam / Thermal Oil / Hot Water / No Heating]
- Cooling method: [Cooling Jacket / Dimple Jacket / Coil / No Cooling]
- Agitation system: [Top Entry Agitator / Anchor Mixer / Paddle / Turbine / High-Shear Mixer / Customized]
- Optional features: [Insulation / Load Cells / Temperature Sensor / Pressure Gauge / Manhole / CIP / PLC Control / Explosion-Proof Motor]
- Certificates: ASME, CE, GMP, UL, ATEX, ISO 9001
- Working pressure: [Atmospheric / Positive Pressure / Vacuum / Specify pressure]
- If you have drawings, we can process them for you.
Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909
$2,470.28 – $2,849.96Price range: $2,470.28 through $2,849.96
Guaranteed Safe Checkout

Recommend RPM: 0-960RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing

Recommend RPM: 0-200RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing

Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For single wall tank

Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For jacket tank

Recommend RPM: 1480/2850 RPM
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion

Recommend RPM: 2800 - 3200 RPM
Viscosity: Low/medium/High viscosity
Application: Liquid powder mixing and homogenizing

Recommend RPM: 0-355RPM
Viscosity: Low/medium viscosity
Application: Install at bottom, No mechanical seal working condition

Recommend RPM: As above
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion For tank volume >300L
1000L Jacketed Melting Tank for Controlled Heating
This 1000L double-jacketed tank is intended for processors that need to soften, melt, or maintain temperature-sensitive materials under controlled conditions. Typical duties include chocolate, edible fats, waxes, yogurt bases, and selected chemical formulations. The tank geometry, working volume, outlet arrangement, and agitator are normally finalized around viscosity, batch size, heating time, and cleaning requirements rather than capacity alone.
Construction and Fabrication
Product-contact parts are commonly specified in 304 stainless steel, with 316 or 316L considered when chlorides, acids, salts, or pharmaceutical cleanliness requirements are present. We determine the suitable grade from the formulation and cleaning chemistry. Continuous sanitary welds, internal grinding, and a specified polish level reduce product retention. Mechanical seals, gaskets, manway design, and drain details also require attention; a tank that cannot drain or be inspected properly will create avoidable sanitation and maintenance work.
Heating and Mixing Design
The double jacket can be configured around hot water, thermal oil, or another approved heating medium. Required jacket area and heat-transfer performance depend on product viscosity, starting temperature, batch size, target temperature, and available utilities. Temperature control may use a sensor in the vessel, jacket control, or both. Chocolate and fat service often benefits from gentle, continuous agitation, while wax or chemical products may need a different impeller profile and motor torque. Drive selection depends on viscosity, solids content, speed range, and whether the agitator starts under a cold, heavy load.
Technical Specifications
| Item | Reference |
|---|---|
| Nominal tank capacity | 1000 L |
| Tank construction | Double-jacketed stainless steel vessel |
| Heating medium | Selected according to process and plant utilities |
| Agitator and drive | Engineered from viscosity, torque, and mixing duty |
| Product-contact finish | Specified by hygiene, product, and cleaning method |
Common Questions
Can one configuration handle chocolate and chemicals? Not automatically. Materials, seals, finish, heating limits, and cleaning procedures must match the formulation.
Is 1000 L the working volume? Confirm this before ordering. Headspace, foaming, expansion, and agitator clearance affect usable batch volume.
What should accompany a quotation request? Provide product viscosity, density, batch size, melting temperature, heating time, solids content, cleaning method, power supply, and required outlet or transfer connection. These details allow us to size the jacket, motor, reducer, impeller, controls, and seals with fewer assumptions.
