Jacketed Fermentation Bioreactor Mixing Tank with Heating and Cooling
A jacketed mixing tank for fermentation and batch processes requiring controlled heating, cooling, and agitation. Configure the vessel, stainless steel grade, internal finish, jacket service, and mixing system around product properties, batch volume, utilities, and cleaning requirements. Share your process temperature profile and material details to help determine a suitable design.
- Capacity: 50 liters to 30,000 liters
- Mixer power: 1.5 kW to 55 kW
- Material: [SUS304 / SUS316L]
- Voltage: 110V / 220V / 380V / 400V / 440V / 480V / 600V
- Heating method: [Electric / Steam / Thermal Oil / Hot Water / No Heating]
- Cooling method: [Cooling Jacket / Dimple Jacket / Coil / No Cooling]
- Agitation system: [Top Entry Agitator / Anchor Mixer / Paddle / Turbine / High-Shear Mixer / Customized]
- Optional features: [Insulation / Load Cells / Temperature Sensor / Pressure Gauge / Manhole / CIP / PLC Control / Explosion-Proof Motor]
- Certificates: ASME, CE, GMP, UL, ATEX, ISO 9001
- Working pressure: [Atmospheric / Positive Pressure / Vacuum / Specify pressure]
- If you have drawings, we can process them for you.
Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909
Price range: $2,821.32 through $3,191.20
Guaranteed Safe Checkout
Recommend RPM: 0-960RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing
Recommend RPM: 0-200RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing
Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For single wall tank
Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For jacket tank
Recommend RPM: 1480/2850 RPM
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion
Recommend RPM: 2800 - 3200 RPM
Viscosity: Low/medium/High viscosity
Application: Liquid powder mixing and homogenizing
Recommend RPM: 0-355RPM
Viscosity: Low/medium viscosity
Application: Install at bottom, No mechanical seal working condition
Recommend RPM: As above
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion For tank volume >300L
Jacketed Mixing Tank for Fermentation and Process Heating
This vessel combines mixing with jacket-based temperature control for batches that need heating, cooling, or both during processing. Typical uses include fermentation, blending, and temperature-sensitive preparation in food, beverage, chemical, pharmaceutical, and cosmetic production. The required working volume, batch behavior, and process temperature range determine the vessel layout and control approach; these details need to be defined before sizing the equipment.
We manufacture the product-contact vessel and jacket to the agreed process requirements. Stainless steel grade depends on the media, cleaning chemicals, and required corrosion resistance. Weld design, internal finish, and drainability should match the hygiene and cleaning standard of the application. Product-contact welds can be finished to the specified surface condition, while jacket connections and pressure-related details must be designed for the selected heating or cooling medium. Seal material and shaft arrangement also depend on product compatibility and operating conditions.
Heating, Cooling, and Agitation
The double jacket can be configured for steam, electrical heating, cooling, or a defined combination. Steam heating requires suitable utility and pressure-design information; electric heating requires agreement on power supply and temperature-control strategy. Cooling capacity depends on the cooling medium, inlet temperature, batch size, and heat load. A control system can be specified around the required temperature range and process sequence rather than assumed from the product name.
Agitator type, impeller geometry, motor, and gearbox are selected according to viscosity, solids content, batch volume, and mixing objective. A design suited to a thin liquid may not provide adequate turnover in a viscous fermentation medium. We review operating speed, torque needs, aeration or shear sensitivity, and cleaning access before finalizing the drive arrangement.
Configuration Data
| Item | Specification basis |
|---|---|
| Capacity | Set by working volume and batch size |
| Product-contact material | Selected for product and cleaning chemistry |
| Jacket service | Steam, electric heating, cooling, or combination |
| Agitation system | Selected for viscosity and process duty |
| Controls and finish | Defined by process and sanitation requirements |
FAQs
Can one tank handle heating and cooling? Yes, if the jacket and utilities are designed for the specified services and operating sequence.
What information is needed for a quotation? Provide batch and working volume, product properties, temperature profile, heating and cooling utilities, cleaning method, material requirements, and available power.
How should capacity be chosen? Account for usable working volume, headspace, foaming, and agitation performance—not nominal vessel volume alone. Sharing a process description lets our engineers recommend a practical configuration.
