Industrial High Shear Liquid Mixer Electric Heating Soap Shampoo
- Material: 304 or 316L
- Voltage: 110V 208V 220V 380V 400V 415V 480V 600V
- Certificates: CE, GMP, UL, ATEX, ISO 9001
- Power：0.75KW-55KW （1 HP – 74 HP）
- Motor brands: ABB, Chinese brands, SEW, Siemens (optional)
- 1-year free warranty with door-to-door delivery.
- Optional: Variable-frequency drive, control panel
- MADE IN CHINA
- We have it in stock.
Please contact our sales team before placing your order.
Email:info@ace-chn.com
Tel:+86 18626835909
WeChat: ace-chn
Price range: $1,399.73 through $1,513.25
Guaranteed Safe Checkout
We manufacture and sell the following types of mixers
Mix, emulsify, homogenize, disintegrate and dissolve
Ideal for disintegrating solids and incorporating powders
Reduce mixing times by up to 80%
Reduce mixing times by up to 90%
Quickly disperse and hydrate powders, even at higher viscosities
Easy to move and lift
Features heating, cooling, vacuum, and other functions
Recommended RPM: 1480/2850 RPM
Configured around the batch
This batch high shear mixer handles wetting, dispersion, emulsification, and powder incorporation in one vessel. Soap and shampoo are common duties, along with food, cosmetic, pharmaceutical, chemical, and coating products. The mixer is not selected by product name alone. Batch size, viscosity, solids loading, and vessel charging determine the head, motor, and mounting.
We build high shear mixing equipment for production use. Industrial high shear mixer motor power ranges from 1.5 to 55 kW. A variable speed high shear mixer with VFD can run from 0 to 3000 rpm, depending on motor and configuration. Electrical supply is confirmed for 220V to 480V, including frequency and phase. Wetted parts on this stainless steel high shear mixer can be 304 or 316L.
What to define before a quote
- Batch volume and vessel dimensions, including working and maximum levels.
- Product viscosity, solids content, and powder wetting behavior.
- Target mixing speed and motor power.
- Voltage, frequency, and phase at the plant.
- Mix head style and contact material for cleaning and formulation needs.
- Stationary mounting or a portable high shear mixer on a mobile frame.
For a high shear mixer for powder dispersion, the feed method matters as much as rpm. We ask how powder is added, how much air is entrained, and whether the batch is heated. Electric heating configurations for liquid mixing are reviewed with the vessel and controls; heater details are confirmed only after the product and utilities are clear.
Applications and limits
Typical duty includes food and beverage, cosmetics and personal care, pharmaceutical and healthcare preparations, chemical processing, and compatible paints and coatings. Liquid-liquid emulsification and powder dispersion are common. Suitable head design, material, and parameters depend on viscosity, ingredients, and process requirements. A shampoo batch and a filled coating are not the same mixing problem.
FAQ
Can I adjust speed during a batch? Yes, with an optional VFD. The usable range is confirmed against the selected motor and configuration.
Which stainless steel should we choose? 304 or 316L are available for contact parts. The choice should account for the formulation, cleaning chemicals, and surface requirements.
Can the mixer be portable? Yes. We can discuss fixed mounting or a mobile high shear mixer arrangement based on vessel layout and operator access.
What information speeds a recommendation? Send batch size, product viscosity and solids, target rpm, motor power, heating needs, and local voltage, frequency, and phase to Ace Mixer for a configuration recommendation and quote.
Industrial high shear mixer for batch mixing, emulsifying, dispersing, and powder incorporation in soap, shampoo, food, cosmetic, pharmaceutical, and chemical production. Configure motor power from 1.5 to 55 kW, 220V to 480V electrics, optional VFD speed control, and 304 or 316L stainless steel contact parts. Ace Mixer builds stationary or portable units around your vessel, formulation, and local electrical supply.
