500L Stainless Steel Double-Layer High Shear Vacuum Emulsion Reactor
500L stainless steel double-layer high shear vacuum emulsion reactor with electric heating. Designed for cosmetics, pharmaceuticals, and chemical processing. Features mirror-polished interior, vacuum operation, and precise temperature control. Customizable materials and seals.
- Capacity: 50 liters to 30,000 liters
- Mixer power: 1.5 kW to 55 kW
- Material: [SUS304 / SUS316L]
- Voltage: 110V / 220V / 380V / 400V / 440V / 480V / 600V
- Heating method: [Electric / Steam / Thermal Oil / Hot Water / No Heating]
- Cooling method: [Cooling Jacket / Dimple Jacket / Coil / No Cooling]
- Agitation system: [Top Entry Agitator / Anchor Mixer / Paddle / Turbine / High-Shear Mixer / Customized]
- Optional features: [Insulation / Load Cells / Temperature Sensor / Pressure Gauge / Manhole / CIP / PLC Control / Explosion-Proof Motor]
- Certificates: ASME, CE, GMP, UL, ATEX, ISO 9001
- Working pressure: [Atmospheric / Positive Pressure / Vacuum / Specify pressure]
- If you have drawings, we can process them for you.
Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909
Price range: $3,028.83 through $3,645.80
Guaranteed Safe Checkout
Recommend RPM: 0-960RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing
Recommend RPM: 0-200RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing
Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For single wall tank
Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For jacket tank
Recommend RPM: 1480/2850 RPM
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion
Recommend RPM: 2800 - 3200 RPM
Viscosity: Low/medium/High viscosity
Application: Liquid powder mixing and homogenizing
Recommend RPM: 0-355RPM
Viscosity: Low/medium viscosity
Application: Install at bottom, No mechanical seal working condition
Recommend RPM: As above
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion For tank volume >300L
We build this 500L reactor for production lines where emulsion quality and batch consistency matter more than flashy features. It is a double-layer stainless steel vessel with electric heating, a high-shear mixer, and vacuum capability—engineered for processes like cosmetic creams, pharmaceutical ointments, and chemical dispersions that require controlled heating, homogenization, and deaeration in one unit.
The inner shell is welded from 304 or 316L stainless steel, depending on your material compatibility needs. We polish internal surfaces to a mirror finish (Ra ≤ 0.4 µm) to meet hygiene standards and make cleaning between batches straightforward. The outer layer acts as a heating jacket, and we fit electric heating elements that allow precise temperature control from ambient up to 150°C, with cooling options available for exothermic reactions. The reactor is rated for vacuum operation, which helps remove air bubbles during emulsification and improves product stability.
Our high-shear agitator combines a bottom-mounted homogenizer with a counter-rotating anchor scraper. This setup handles viscosities up to 50,000 cP, producing fine droplets and uniform particle size. The shaft seal is a mechanical double seal with a flush reservoir, so you can run under vacuum without leakage. All contact parts are made of stainless steel, and the control panel can be integrated with your existing PLC system.
Technical Specifications
| Nominal Capacity | 500 L |
| Material | SS304 / SS316L (optional) |
| Heating | Electric heating jacket |
| Cooling | Optional cooling coil or jacket |
| Operating Pressure | Vacuum to atmospheric (customizable) |
| Mixer Type | High-shear homogenizer + anchor scraper |
| Seal | Mechanical double seal |
| Surface Finish | Internal mirror polish, external brushed |
FAQ
Q: Can I use this reactor for acid or alkaline materials?
A: Yes, but you need to specify the chemical composition and concentration. We will recommend the correct grade (304 vs 316L) and may adjust the seal material.
Q: What is the maximum working temperature?
A: With electric heating, we typically design for 150°C. If you need higher, we can switch to thermal oil heating—just tell us your process temperature.
Q: How do I clean the reactor between batches?
A: The mirror-polished surface and spray ball (optional) allow CIP cleaning. You can also remove the agitator shaft for manual cleaning if needed.
Q: Do you provide explosion-proof versions?
A: Yes, we can fit explosion-proof motors and control boxes for flammable solvents. This must be specified in your inquiry.
Q: What is the lead time?
A> Typically 30–45 days after drawing approval, depending on customization level.
Before requesting a quote, please prepare the following details: the exact materials you will process (including chemical name and concentration), batch volume and working volume, required operating temperature and pressure, whether you need vacuum or inert gas blanketing, the target viscosity range, and your mixing requirements (shear rate, particle size). Also note any cleaning or compliance standards (e.g., FDA, cGMP). With these inputs, our engineers can confirm the vessel design, agitator configuration, heating/cooling capacity, and sealing system that fits your production line. Send us your process requirements and we will provide a technical proposal and quotation.
