30000L Vertical Edible Oil Storage Tank | 30 Ton Vegetable Oil Tank
Vertical 30,000L edible oil storage tank made of food-grade stainless steel. Full drainage bottom, polished interior, and optional heating or insulation. Built for bulk vegetable oil storage.
- Tank Capacity: [50L–100,000L or specify actual capacity]
- Tank Type: [Vertical / Horizontal / Single-wall / Double-wall / Jacketed]
- Material: 304 or 316L
- Optional Features: [Insulation / Heating / Cooling / Agitator / Level Gauge / Manway / CIP Spray Ball / Load Cells / Wheels / Custom Connections]
- Surface Finish: [2B / Brushed / Polished / Mirror Polish]
- If you have drawings, we can process them for you.
Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909
Price range: $2,530.02 through $3,071.95
Guaranteed Safe Checkout
Vertical 30000L Edible Oil Storage Tank – Built for Bulk Oil Handling
This 30,000-liter vertical tank is designed for storing edible oils, vegetable oils, and similar food-grade liquids. We manufacture it in our own workshop, and every weld, joint, and surface finish is done with the product in mind.
The tank body is fabricated from stainless steel sheet, with the grade selected based on the oil being stored and the cleaning chemicals used in your process. For most edible oil applications, SUS304 is sufficient. If your process involves higher chloride exposure or more aggressive cleaning agents, we recommend SUS316L. We do not guess – we ask about your product and washdown routine before quoting.
Vertical geometry suits facilities with limited floor space. The cone bottom or dished bottom design allows full drainage, which matters when you switch between oil types or need to empty the tank completely for cleaning. The interior is polished to a food-grade finish, and all internal welds are ground smooth to prevent oil residue from clinging to seams.
We offer options for level sensors, temperature probes, insulation, and heating coils – but only if your operation actually needs them. If you are storing oil at ambient temperature in a climate-controlled building, you likely do not need heating. If you are in a cold region and need to keep oil pumpable, we will size the heating surface accordingly.
Technical Specifications
| Capacity | 30,000 L / 30 tons (approx., based on oil density) |
|---|---|
| Material | SUS304 / SUS316L (selected per application) |
| Orientation | Vertical |
| Bottom Type | Cone or dished (full drainage) |
| Surface Finish | Food-grade interior polish, exterior brushed or matte |
| Connections | Inlet, outlet, vent, manhole – sized per your piping |
| Options | Insulation, heating coils, level sensors, temperature probes, agitator |
Frequently Asked Questions
How do I choose between SUS304 and SUS316L?
If your oil is neutral and your cleaning uses standard caustic or mild acid, SUS304 is adequate. If you use higher chloride sanitizers or store more acidic oils, go with SUS316L. We can advise once we know your full process.
Do I need a cone bottom?
If you intend to drain the tank fully between batches, yes. A flat bottom will leave a heel of oil that can go rancid and contaminate the next batch.
Can this tank be used for pressure or vacuum?
No. This is an atmospheric storage tank. If you need vacuum or pressure, that is a different design with different wall thickness and head ratings. Tell us your requirement and we will quote accordingly.
What information do you need for a quote?
We need the product to be stored, capacity, material grade preference, operating temperature, site dimensions, and any special fittings like agitators or heating. With that, we can prepare a proper configuration and price.
Contact us with your storage details – product type, required capacity, material grade, working temperature, and available space. We will respond with a configuration recommendation and a firm quotation.
