Vacuum Emulsifying Mixer for Cream, Shampoo, Soap and Paste

A configurable vacuum emulsifying mixer for manufacturing cosmetic creams, shampoo, liquid soap, and compatible paste products. Vessel volume, contact materials, agitator and homogenizer arrangement, seals, heating, and controls are selected around the batch process. Share product viscosity, batch size, temperature targets, cleaning method, and vacuum requirements to help determine a suitable configuration.

Capacity: 50 liters to 30,000 liters
Mixer power: 1.5 kW to 55 kW
Material: 304 or 316L
Voltage: 110V to 600V
Heating method: Electric or steam heating
Layer:single/double jacket/three jacket
Mixer types: Impeller-type, Anchor-type, Turbine-type, High-shear-type, Magnetic mixer, Anchor-type mixer with scrapers,dispersing
Optional: platform, wheels, ladder,variable frequency drive,explosion-proof device
Certificates: ASME, CE, GMP, UL, ATEX, ISO 9001
Our equipment supports customisation, global delivery, and a 1-year warranty.
If you have drawings, we can process them for you.

Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909

Price range: $3,114.98 through $3,683.78

Ask For A Quotation

Guaranteed Safe Checkout

Vacuum Mixing for Creams, Shampoos, and Liquid Soaps

Our vacuum emulsifying mixer is configured around the product’s viscosity, batch size, and processing sequence. It can combine a main vessel, an emulsifying homogenizer, and an anchor or other selected agitator to handle wetting, blending, and dispersion in one system. Vacuum processing can help reduce entrained air, which matters when bubbles affect filling, appearance, or product stability. The required shear level depends on the formula; a homogenizer is not a substitute for appropriate bulk circulation.

Materials and fabrication

Product-contact parts are commonly specified in 316L stainless steel when formulation chemistry or cleaning requirements call for it; 304 stainless steel may suit less demanding products. Final material selection should account for ingredients, cleaning agents, temperature, and applicable plant requirements. We establish weld finishing and internal surface requirements with the purchaser, since surface finish targets and inspection needs vary by process. Seal materials and shaft-seal design also need to match product compatibility, vacuum conditions, cleaning method, and operating temperature.

Drive, heating, and controls

Agitator type, impeller geometry, motor, and gearbox are selected from the batch’s viscosity range and mixing duty. An anchor agitator may support wall-side movement in viscous products; a separate high-shear head can provide localized emulsification. Actual performance depends on vessel geometry, batch level, and ingredient addition sequence. Where heating or cooling is required, the vessel may be designed with a jacket or another specified heat-transfer arrangement. Temperature control, heating medium, and required ramp time should be defined from the process rather than assumed.

Configuration points

Item	Configuration basis
Working volume	Batch size, fill range, and headspace for vacuum operation
Contact materials	Product chemistry, cleaning agents, and finish requirements
Mixing system	Viscosity, shear sensitivity, circulation, and batch sequence
Heating and cooling	Process temperatures, utilities, and heat-up or cool-down targets
Controls and cleaning	Operator needs, plant standards, and cleaning procedure

Applications and purchasing questions

Typical applications include cosmetic creams and lotions, shampoo, liquid soap, and compatible paste products. A frequent sizing error is choosing only by vessel capacity: a high-viscosity batch may need different drive torque and circulation than a free-flowing liquid of the same volume.

Can one mixer handle several formulas? Often, but viscosity range, shear requirements, and cleaning changeover must be reviewed. What should we send for a quotation? Provide batch volume, ingredient or product viscosity information, process steps, target temperatures, vacuum needs, cleaning method, available utilities, and any site or electrical standards. These details allow our engineers to recommend a practical configuration without guessing at critical specifications.
