Stainless steel reactor mixing tanks for food, beverage, and detergent production. Customizable capacity, heating, cooling, and agitation systems built to your process requirements. Factory-direct fabrication with 304/316L stainless steel.

Capacity: 50 liters to 30,000 liters
Mixer power: 1.5 kW to 55 kW
Material: [SUS304 / SUS316L]
Voltage: 110V / 220V / 380V / 400V / 440V / 480V / 600V
Heating method: [Electric / Steam / Thermal Oil / Hot Water / No Heating]
Cooling method: [Cooling Jacket / Dimple Jacket / Coil / No Cooling]
Agitation system: [Top Entry Agitator / Anchor Mixer / Paddle / Turbine / High-Shear Mixer / Customized]
Optional features: [Insulation / Load Cells / Temperature Sensor / Pressure Gauge / Manhole / CIP / PLC Control / Explosion-Proof Motor]
Certificates: ASME, CE, GMP, UL, ATEX, ISO 9001
Working pressure: [Atmospheric / Positive Pressure / Vacuum / Specify pressure]
If you have drawings, we can process them for you.

Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909

Price range: $3,117.71 through $3,879.68

Ask For A Quotation

Guaranteed Safe Checkout

When you\’re running a food, beverage, or detergent line, the mixing vessel is where your formulation comes together. We build stainless steel reactor tanks that handle the day-to-day realities of production—heat, agitation, cleaning cycles, and batch consistency.

Our reactors are fabricated from 304 or 316L stainless steel, depending on your process chemistry. For detergent plants dealing with chlorides or acidic formulations, 316L is the safer call. For food and beverage applications, we match the interior finish to your cleaning requirements—typically a 0.4 to 0.6 μm Ra surface polish that drains clean and resists bacterial hold-up. Welds are fully penetrated and ground smooth, because a rough weld bead is where product collects and where pitting starts.

The stirring system is where we pay close attention. A simple anchor agitator works for low-viscosity blending. But if you\’re emulsifying, suspending solids, or handling shear-sensitive ingredients, we\’ll recommend a turbine or counter-rotating setup. We also size the motor and gearbox based on the actual viscosity range of your product, not a guess from a brochure.

Heating and cooling are configured around your thermal requirements. We build jacketed vessels for steam, thermal oil, or hot water heating, and we can add internal coils or an external heat exchanger loop for faster temperature response. Pressure ratings are selected to match your process—atmospheric, pressurized, or full vacuum operation—and we verify the design against your specified working conditions.

Technical Specifications

Capacity	Custom (50L to 30,000L)
Material	SS304 / SS316L
Internal Wall Thickness	Per pressure rating & vessel size
Heating	Steam / Thermal oil / Electric
Cooling	Jacket / Coil / External loop
Working Pressure	Atmospheric to 1.0 MPa (or custom)
Design Temperature	Up to 180°C (or custom)
Stirring	Anchor / Turbine / Counter-rotating / Custom
Sealing	Mechanical seal / Stuffing box
Surface Finish	Mirror polish / Satin / Pickled
Options	CIP spray ball, manhole, sight glass, PLC control

Choosing the Right Vessel

Tell us what you\’re processing. The chemical composition, concentration, viscosity, and solid content of your product determine the material grade, agitator type, and seal specification. Batch volume and working volume tell us the tank size and motor power. Operating temperature and pressure set the design envelope. And your cleaning method—manual or CIP—affects the surface finish and nozzle placement.

We\’ve built these tanks for sauce producers, beverage bottlers, and detergent manufacturers alike. Each one is configured around the specific process, not assembled from a standard template. That\’s the advantage of working directly with the factory—you get the customization you actually need, without paying for features you don\’t.

To get a proper quote, send us your material type, batch capacity, operating temperature, pressure requirements, and mixing expectations. We\’ll recommend the right configuration and provide a detailed specification sheet for your review.
