Food Grade Double-Open Mixing Tank with Paddle and Scraper
A food-grade mixing tank with paddle and wall scraper for processing honey, juice drinks, sauces, jam, and ketchup. Tank capacity, stainless steel grade, surface finish, drive, agitator geometry, seals, and optional heating are selected around the recipe, batch size, viscosity, cleaning method, and production requirements.
- Capacity: 50 liters to 30,000 liters
- Mixer power: 1.5 kW to 55 kW
- Material: 304 or 316L
- Voltage: 110V to 600V
- Heating method: Electric or steam heating
- Layer:single/double jacket/three jacket
- Mixer types: Impeller-type, Anchor-type, Turbine-type, High-shear-type, Magnetic mixer, Anchor-type mixer with scrapers,dispersing
- Optional: platform, wheels, ladder,variable frequency drive,explosion-proof device
- Certificates: ASME, CE, GMP, UL, ATEX, ISO 9001
- Our equipment supports customisation, global delivery, and a 1-year warranty.
- If you have drawings, we can process them for you.
Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909
Price range: $2,147.05 through $2,419.08
Guaranteed Safe Checkout
Recommend RPM: 0-960RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing
Recommend RPM: 0-200RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing
Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For single wall tank
Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For jacket tank
Recommend RPM: 1480/2850 RPM
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion
Recommend RPM: 2800 - 3200 RPM
Viscosity: Low/medium/High viscosity
Application: Liquid powder mixing and homogenizing
Recommend RPM: 0-355RPM
Viscosity: Low/medium viscosity
Application: Install at bottom, No mechanical seal working condition
Recommend RPM: As above
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion For tank volume >300L
Mixing tank for viscous food products
This food-grade industrial mixing tank is intended for batches such as honey, fruit and vegetable juice drinks, sauces, jam, and ketchup. A paddle with a wall scraper can help move thicker product through the vessel and reduce material clinging to the tank wall during mixing. The suitable geometry and operating speed depend on batch size, viscosity, solids content, and the desired mixing result. “Double open” can refer to different vessel or cover arrangements, so we confirm the intended opening design before fabrication.
Construction and process configuration
We select wetted-part materials around the recipe, cleaning chemicals, chloride exposure, and required sanitation practice. 304 stainless steel may suit many food processes; 316L can be specified where the product or cleaning environment calls for greater corrosion resistance. Welds in product-contact areas should be finished to the agreed hygienic standard, with polishing level and surface-finish requirements documented before production. Seals and scraper materials must also be compatible with product temperature, ingredients, and washdown chemicals.
Drive selection is based on viscosity, working volume, scraper load, and whether the mixer must start with a full or settled batch. Gear reducer, motor power, speed range, and any speed control are configured to the process rather than assumed from the product name. Paddle shape and scraper material affect circulation, wall clearance, wear, and cleanability; a trial or process review may be useful for products with fruit pieces or changing viscosity. If heating is needed, a jacket or another agreed heating arrangement can be evaluated with the required temperature range, heat-up time, and control method.
Typical specification basis
| Item | Configuration basis |
|---|---|
| Applications | Honey, juice drinks, sauces, jam, and ketchup |
| Agitator | Paddle and wall scraper, sized to product behavior |
| Wetted material | 304 or 316L stainless steel, confirmed by process conditions |
| Capacity, speed, finish, heating | Custom; define from batch and production requirements |
Questions to resolve before ordering
Can one configuration handle both drinks and jam? Possibly, but low-viscosity beverages and high-solids jam require different circulation and drive considerations. Share both recipes and operating conditions for review.
What information is needed for a quotation? Provide working and maximum batch volume, ingredients and solids, viscosity or a practical description, target temperature, mixing time, cleaning method, installation limits, and required opening arrangement. These details let our engineers recommend a tank and drive configuration without guessing at production-critical specifications.
