Batch High Shear Homogenizer Mixer | Food Grade, Cosmetic & Ice Cream
- Material: 304 or 316L
- Voltage: 110V 208V 220V 380V 400V 415V 480V 600V
- Certificates: CE, GMP, UL, ATEX, ISO 9001
- Power：0.75KW-55KW （1 HP – 74 HP）
- Motor brands: ABB, Chinese brands, SEW, Siemens (optional)
- 1-year free warranty with door-to-door delivery.
- Optional: Variable-frequency drive, control panel
- MADE IN CHINA
- We have it in stock.
Please contact our sales team before placing your order.
Email:info@ace-chn.com
Tel:+86 18626835909
WeChat: ace-chn
Price range: $1,090.54 through $1,156.84
Guaranteed Safe Checkout
We manufacture and sell the following types of mixers
Mix, emulsify, homogenize, disintegrate and dissolve
Ideal for disintegrating solids and incorporating powders
Reduce mixing times by up to 80%
Reduce mixing times by up to 90%
Quickly disperse and hydrate powders, even at higher viscosities
Easy to move and lift
Features heating, cooling, vacuum, and other functions
Recommended RPM: 1480/2850 RPM
Batches rarely fail at the homogenizing stage because the mixer was undersized. They fail because the shear head, the shaft speed, and the tank geometry were never matched to the product. We build this food grade batch high shear homogenizer mixer around the material it has to move — a 5,000 cps ice cream base and a 40,000 cps cosmetic cream are two different machines, even when the frame looks the same.
Configurable specifications
- Speed control: VFD optional, 0–3000 rpm adjustable depending on motor and configuration
- Motor power: 1.5 kW to 55 kW, selected against batch size and viscosity
- Voltage: 220V to 480V — voltage, frequency, phase and electrical arrangement confirmed for your market before build
- Mixing functions: high shear, dispersion, emulsification, and powder wetting into liquids
- Wetted materials: 304 or 316L stainless steel; contact parts specified to your product
- Mounting: portable or fixed frames, open-tank or closed-vessel entry
Sizing before quoting
Three numbers drive the recommendation: working batch volume, product viscosity at process temperature, and the solids you intend to disperse. A light syrup moves easily at 1,500 rpm with a 4 kW drive; a pigment slurry of the same volume may need twice the power and a different rotor-stator profile. Tell us the vessel diameter and whether the head enters from the top or the side — a portable high shear mixer on a small tank behaves nothing like a fixed unit on a jacketed 2,000 L vessel.
Where these units run
Ice cream premix and sauces, cosmetic creams and lotions, pharmaceutical suspensions, chemical emulsions, and compatible coatings. Powder incorporation into liquids accounts for a large share of inquiries. Head style, stainless grade and operating parameters still depend on viscosity, formulation and process conditions — we will say so rather than guess.
Common questions
Can one unit handle both ice cream mix and cosmetics? Often yes on the mechanical side, but the wetted finish, cleaning access and head choice differ.
Is the VFD necessary? For formulations that thicken during processing, yes. Fixed speed is workable for repeat single-product runs.
How long is delivery? Depends on motor, control package and material grade; confirmed at order.
Send your batch size, material characteristics, target rpm, required motor power and local electrical specification, and our engineers will return a specific configuration and price.
A configurable food grade batch high shear homogenizer mixer for cosmetics, ice cream and industrial emulsions. Motor power from 1.5 kW to 55 kW, optional VFD speed control up to 3000 rpm, 304 or 316L wetted parts, and 220V–480V electrical options built to your market requirements.
