500L Stainless Steel Jacketed Vacuum Reactor with Anchor Scraping Wall Stirrer
500L stainless steel vacuum reactor with anchor scraping wall stirrer, jacket and coil heating. Designed for viscous mixing, temperature control, and vacuum operation in chemical, pharmaceutical, and food processes. Customizable material grade, seal type, and agitation speed.
- Capacity: 50 liters to 30,000 liters
- Mixer power: 1.5 kW to 55 kW
- Material: [SUS304 / SUS316L]
- Voltage: 110V / 220V / 380V / 400V / 440V / 480V / 600V
- Heating method: [Electric / Steam / Thermal Oil / Hot Water / No Heating]
- Cooling method: [Cooling Jacket / Dimple Jacket / Coil / No Cooling]
- Agitation system: [Top Entry Agitator / Anchor Mixer / Paddle / Turbine / High-Shear Mixer / Customized]
- Optional features: [Insulation / Load Cells / Temperature Sensor / Pressure Gauge / Manhole / CIP / PLC Control / Explosion-Proof Motor]
- Certificates: ASME, CE, GMP, UL, ATEX, ISO 9001
- Working pressure: [Atmospheric / Positive Pressure / Vacuum / Specify pressure]
- If you have drawings, we can process them for you.
Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909
Price range: $3,996.30 through $4,867.09
Guaranteed Safe Checkout
Recommend RPM: 0-960RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing
Recommend RPM: 0-200RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing
Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For single wall tank
Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For jacket tank
Recommend RPM: 1480/2850 RPM
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion
Recommend RPM: 2800 - 3200 RPM
Viscosity: Low/medium/High viscosity
Application: Liquid powder mixing and homogenizing
Recommend RPM: 0-355RPM
Viscosity: Low/medium viscosity
Application: Install at bottom, No mechanical seal working condition
Recommend RPM: As above
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion For tank volume >300L
This 500-liter reactor is built for processes that demand reliable heating, vacuum capability, and thorough mixing. The anchor stirrer with wall scrapers is the key feature here — it keeps material moving along the heated surfaces, which matters when you\’re dealing with viscous products or crystallization tendencies.
We fabricate the vessel from 304 or 316L stainless steel, depending on your process chemistry. The jacket and internal coil give you flexible heating options — steam, thermal oil, or cooling water — depending on what your plant has available. The vacuum rating allows operation under reduced pressure, which is useful for solvent recovery or moisture removal.
For industries like pharmaceuticals, fine chemicals, or food processing, this reactor handles duties such as mixing slurries, dissolving solids, or conducting reactions under controlled temperature. The scraped-wall design reduces product buildup on the vessel wall, which improves heat transfer consistency batch after batch.
All wetted parts are polished to a sanitary finish, with welds ground smooth to minimize dead zones. The mechanical seal is selected based on your operating pressure and solvent type — we\’ll confirm the right configuration during quoting.
Technical Specifications
| Capacity | 500L (working volume approx. 400L) |
| Material | SS304 / SS316L |
| Heating | Jacket + internal coil (steam or thermal oil) |
| Stirring | Anchor impeller with PTFE or SS scrapers |
| Seal | Mechanical seal (customizable) |
| Surface | Internal mirror polish, external matte or brushed |
FAQ
Q: What materials can this reactor handle?
It depends on the alloy and your chemical compatibility. For acidic or chloride-containing processes, we typically recommend 316L. Send us your material safety data sheet (SDS) for a proper recommendation.
Q: Can the stirring speed be adjusted?
Yes, we offer variable frequency drive (VFD) control for the agitator motor. This allows you to adjust the mixing intensity based on viscosity changes during the batch.
Q: How do I clean the reactor between batches?
The polished internal surfaces and smooth welds make manual cleaning straightforward. For automated cleaning, we can add spray balls (CIP) as an option.
Request a Quote
To get the right configuration, please provide your process details: the material being processed, batch size, operating temperature and pressure, viscosity, and your heating/cooling utility availability. With that information, we can recommend the suitable material grade, seal type, and stirrer design — and give you a firm quotation.
