500L 1000L Stainless Steel Hydrolysis Reactor Tank | Jacketed Enzymatic Water Treatment Vessel
500L and 1000L stainless steel hydrolysis reactor tanks for enzymatic and water treatment processes. Jacketed, customizable agitation, SS304/SS316L construction. Built for controlled heating, cooling, and clean operation.
- Capacity: 50 liters to 30,000 liters
- Mixer power: 1.5 kW to 55 kW
- Material: [SUS304 / SUS316L]
- Voltage: 110V / 220V / 380V / 400V / 440V / 480V / 600V
- Heating method: [Electric / Steam / Thermal Oil / Hot Water / No Heating]
- Cooling method: [Cooling Jacket / Dimple Jacket / Coil / No Cooling]
- Agitation system: [Top Entry Agitator / Anchor Mixer / Paddle / Turbine / High-Shear Mixer / Customized]
- Optional features: [Insulation / Load Cells / Temperature Sensor / Pressure Gauge / Manhole / CIP / PLC Control / Explosion-Proof Motor]
- Certificates: ASME, CE, GMP, UL, ATEX, ISO 9001
- Working pressure: [Atmospheric / Positive Pressure / Vacuum / Specify pressure]
- If you have drawings, we can process them for you.
Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909
Price range: $3,078.76 through $3,797.03
Guaranteed Safe Checkout
Recommend RPM: 0-960RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing
Recommend RPM: 0-200RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing
Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For single wall tank
Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For jacket tank
Recommend RPM: 1480/2850 RPM
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion
Recommend RPM: 2800 - 3200 RPM
Viscosity: Low/medium/High viscosity
Application: Liquid powder mixing and homogenizing
Recommend RPM: 0-355RPM
Viscosity: Low/medium viscosity
Application: Install at bottom, No mechanical seal working condition
Recommend RPM: As above
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion For tank volume >300L
Hydrolysis and enzymatic processing place specific demands on a reactor vessel. The tank must handle moderate heat, resist chemical attack from acidic or alkaline feedstocks, and allow thorough mixing without damaging shear-sensitive enzymes. Our 500L and 1000L stainless steel hydrolysis reactor tanks are built with those process conditions in mind.
We fabricate these vessels from SS304 or SS316L, depending on the chloride content and pH of your process stream. For most enzymatic hydrolysis work, SS316L offers better resistance to mild acid conditions and saline environments. The inner shell is polished to a 0.4–0.8 μm Ra finish, which keeps the surface cleanable and reduces the risk of bacterial harborage between batches. Welds are fully penetrated and ground smooth, with no crevices where product can accumulate.
The tank is designed as a jacketed vessel. You can specify electric heating, steam heating, or thermal oil circulation, and the jacket is arranged to provide even heat distribution across the cylindrical section. Cooling options include a spiral jacket or internal coil, depending on whether you need rapid temperature drops after the hydrolysis step. A PTFE or silicone mechanical seal is fitted to the top entry agitator, and we can supply a fully sanitary tri-clamp connection arrangement if your process requires it.
Agitation is matched to the application. For enzymatic hydrolysis, a high-shear impeller can denature the enzyme; we typically recommend a pitched-blade turbine or anchor agitator with a speed range that provides good bulk mixing at low to moderate shear. If your process involves suspended solids, we can add a bottom entry or side entry impeller to keep particles in suspension.
Typical Applications
- Enzymatic hydrolysis of proteins and starches in food processing
- Cellulose and biomass pretreatment in biofuel research
- Wastewater treatment with enzymatic or chemical hydrolysis stages
- Pharmaceutical intermediate production requiring gentle, controlled reaction conditions
Technical Specifications
| Parameter | Available Range |
|---|---|
| Nominal Volume | 500L / 1000L |
| Material | SS304 / SS316L |
| Inner Shell Thickness | 4mm – 6mm |
| Jacket Type | Spiral / Dimple / Half-pipe |
| Heating Media | Steam / Electric / Thermal Oil |
| Design Pressure | Atmospheric to 0.6MPa (customizable) |
| Design Temperature | 0°C – 180°C |
| Agitator Type | Pitched-blade / Anchor / Custom |
| Seal Type | PTFE / Silicone / Mechanical |
| Surface Finish | 0.4 – 0.8 μm Ra internal |
Buying Checklist
Before ordering, define your process conditions clearly. What is the chemical composition and concentration of your feedstock? What batch volume do you need versus working volume? What operating temperature and pressure will you run at? Is there a vacuum requirement? What is the viscosity and solids content? Do you need heating, cooling, or both? What mixing result are you looking for? These details determine the vessel configuration, not a generic spec sheet.
We build these tanks to order, so you can specify additional ports, sight glasses, spray balls for CIP, or a different discharge valve arrangement. Because we are the manufacturer, you deal directly with the engineering team that designs and builds your vessel.
When you are ready to get a quote, send us your material, batch capacity, operating temperature, pressure requirements, and agitation needs. We will recommend the right configuration and provide a detailed proposal.
