500L 316L Stainless Steel Fractional Crystallization Reactor | GMP Chemical Processing Kettle
500L 316L stainless steel fractional crystallization reactor built to GMP standards. Precision temperature control, custom agitation, and full vacuum capability for chemical processing applications.
- Capacity: 50 liters to 30,000 liters
- Mixer power: 1.5 kW to 55 kW
- Material: [SUS304 / SUS316L]
- Voltage: 110V / 220V / 380V / 400V / 440V / 480V / 600V
- Heating method: [Electric / Steam / Thermal Oil / Hot Water / No Heating]
- Cooling method: [Cooling Jacket / Dimple Jacket / Coil / No Cooling]
- Agitation system: [Top Entry Agitator / Anchor Mixer / Paddle / Turbine / High-Shear Mixer / Customized]
- Optional features: [Insulation / Load Cells / Temperature Sensor / Pressure Gauge / Manhole / CIP / PLC Control / Explosion-Proof Motor]
- Certificates: ASME, CE, GMP, UL, ATEX, ISO 9001
- Working pressure: [Atmospheric / Positive Pressure / Vacuum / Specify pressure]
- If you have drawings, we can process them for you.
Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909
Price range: $3,168.69 through $3,958.96
Guaranteed Safe Checkout
Recommend RPM: 0-960RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing
Recommend RPM: 0-200RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing
Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For single wall tank
Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For jacket tank
Recommend RPM: 1480/2850 RPM
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion
Recommend RPM: 2800 - 3200 RPM
Viscosity: Low/medium/High viscosity
Application: Liquid powder mixing and homogenizing
Recommend RPM: 0-355RPM
Viscosity: Low/medium viscosity
Application: Install at bottom, No mechanical seal working condition
Recommend RPM: As above
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion For tank volume >300L
500L 316L Stainless Steel Fractional Crystallization Reactor
Fractional crystallization demands precise temperature control and a clean, corrosion-resistant environment. This 500L reactor is built for that specific duty. We fabricate the vessel entirely from 316L stainless steel, with wetted parts finished to a mirror polish that minimizes product adhesion and makes cleaning between batches straightforward.
The jacket is designed for both heating and cooling circuits, so you can ramp temperatures up to dissolve solids and then cool slowly to drive selective crystallization. If your process requires especially tight cooling rates, we can add a secondary internal coil or an external circulation loop — just specify your ramp profile when you ask for a quote.
Stirring is handled by a custom agitator. For crystallization, we typically recommend a helical ribbon or anchor with a scraper, depending on your viscosity and crystal size targets. The shaft seal is a mechanical double seal with a flush port, suitable for solvent service and vacuum operation.
We build to GMP standards as standard practice, not as an extra-cost option. That means orbital welds, full traceability documentation, and a surface finish of Ra ≤ 0.4 µm on contact surfaces. You get a reactor that meets regulatory scrutiny without paying a premium for a separate \”GMP version.\”
Technical Specifications
| Nominal Volume | 500 L |
| Material | 316L stainless steel (wetted parts) |
| Design Temperature | 150°C (customizable up to 200°C) |
| Working Pressure | Full vacuum to 0.6 MPa (higher on request) |
| Heating/Cooling | Jacket with optional internal coil |
| Agitator | Anchor, helical ribbon, or turbine — configurable |
| Seal | Double mechanical seal with flush port |
| Surface Finish | Ra ≤ 0.4 µm internal, 180-grit external |
Choosing the Right Configuration
Before you request a quote, gather these details: the chemical composition and concentration of your feed stream, batch size, operating and design temperatures, pressure conditions, and whether you\’ll run under vacuum. Also note the viscosity range and any solids content. If you\’re working with aggressive chlorides or acids, tell us — we may recommend a higher molybdenum alloy or a different gasket material.
Cleaning requirements matter too. If you run multiple products through the same kettle, ask about our CIP spray ball options and drain port placement. For sterile processes, we can add a sanitary clamp connection instead of a flanged outlet.
Request a Quote
Send us your process parameters — material types, batch volume, temperature range, pressure, and mixing requirements. Our engineers will confirm the right vessel configuration and provide a detailed quotation with a drawing for your approval.
