5000L Stainless Steel Bioreactor Pressure Vessel with Motor for Fermentation
5000L stainless steel bioreactor with pressure vessel design and top-mounted motor. Built for industrial fermentation and extraction with polished internals, jacket heating/cooling, and customizable agitation.
- Capacity: 50 liters to 30,000 liters
- Mixer power: 1.5 kW to 55 kW
- Material: [SUS304 / SUS316L]
- Voltage: 110V / 220V / 380V / 400V / 440V / 480V / 600V
- Heating method: [Electric / Steam / Thermal Oil / Hot Water / No Heating]
- Cooling method: [Cooling Jacket / Dimple Jacket / Coil / No Cooling]
- Agitation system: [Top Entry Agitator / Anchor Mixer / Paddle / Turbine / High-Shear Mixer / Customized]
- Optional features: [Insulation / Load Cells / Temperature Sensor / Pressure Gauge / Manhole / CIP / PLC Control / Explosion-Proof Motor]
- Certificates: ASME, CE, GMP, UL, ATEX, ISO 9001
- Working pressure: [Atmospheric / Positive Pressure / Vacuum / Specify pressure]
- If you have drawings, we can process them for you.
Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909
$3,203.70 – $3,909.48Price range: $3,203.70 through $3,909.48
Guaranteed Safe Checkout

Recommend RPM: 0-960RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing

Recommend RPM: 0-200RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing

Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For single wall tank

Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For jacket tank

Recommend RPM: 1480/2850 RPM
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion

Recommend RPM: 2800 - 3200 RPM
Viscosity: Low/medium/High viscosity
Application: Liquid powder mixing and homogenizing

Recommend RPM: 0-355RPM
Viscosity: Low/medium viscosity
Application: Install at bottom, No mechanical seal working condition

Recommend RPM: As above
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion For tank volume >300L
This 5000L stainless steel bioreactor is built for industrial fermentation and extraction processes where pressure integrity and material purity are non-negotiable. We manufacture this vessel for production environments that require consistent thermal control, reliable agitation, and a cleanable internal surface.
The vessel body is constructed from stainless steel with a polished internal finish to minimize bacterial adhesion and simplify CIP/SIP cycles. Welds are fully penetrated and ground smooth at the joints, which matters more in fermentation duty than in simple storage applications. The pressure vessel design means the tank can handle both positive pressure and vacuum conditions, depending on your process configuration.
The integrated motor and agitator assembly is sized for typical fermentation broths with moderate solids content. We fit a mechanical seal on the agitator shaft to prevent contamination and leakage during extended operation. Jacket heating and cooling are provided through the external shell, and the internal coil option can be added when faster heat transfer is required.
Industries that commonly specify this type of reactor include pharmaceutical intermediate production, enzyme manufacturing, biofuel pilot plants, and food ingredient processing. Each application has different demands regarding agitation speed, temperature uniformity, and cleaning frequency, so we leave the mixing configuration adaptable.
Technical Specifications
| Capacity | 5000L (working volume approx. 4000L) |
| Material | SS304 / SS316L stainless steel |
| Inner tank wall thickness | Per design pressure requirements |
| Heating | Jacket / internal coil (optional) |
| Cooling | Jacket / internal coil (optional) |
| Working pressure | Full vacuum to 0.6 MPa (customizable) |
| Design temperature | 0–150°C (higher on request) |
| Stirring system | Top-mounted motor, mechanical seal, impeller type per duty |
| Sealing | Mechanical seal for shaft, PTFE/silicone gaskets |
| Surface finish | Internal mirror polish, external matte or brushed |
| Options | CIP spray ball, sampling valve, sight glass, pressure gauge, temperature probe |
| Industries | Pharma, biotech, food, chemical, cosmetics |
FAQ
Q: What is the working volume versus total volume?
The working volume is typically 80% of the total capacity to leave headspace for foaming and gas expansion during fermentation.
Q: Can I use this for viscous materials?
Yes, but we need to know the viscosity range to select the right impeller type and motor power. High-viscosity broths require anchor or helical ribbon agitators.
Q: What cleaning method is recommended?
CIP spray balls are recommended for routine cleaning. The mirror-polished interior reduces residue buildup, and the vessel is designed to be fully drainable.
Q: Is the pressure rating fixed?
No. We build to your specified design pressure and can certify the vessel accordingly.
When you request a quote, include the following details: the chemical composition of your material, batch volume, operating and design temperature, working pressure, viscosity, and the type of mixing you need. With that information, our engineers will confirm the wall thickness, agitator configuration, and seal type before we send a proposal.
