Vacuum Cosmetic Cream Mixing Tank with Homogenizer and Scraper Agitator
A vacuum cosmetic cream mixing tank can combine frame-scraper agitation with an optional high-shear homogenizer for controlled processing of creams, lotions, and other viscous emulsions. Vessel material, heating or cooling, seal selection, drive sizing, and controls depend on the formulation, batch volume, cleaning method, and production workflow. Share these process details to define a suitable configuration.
- Capacity: 50 liters to 30,000 liters
- Mixer power: 1.5 kW to 55 kW
- Material: 304 or 316L
- Voltage: 110V to 600V
- Heating method: Electric or steam heating
- Layer:single/double jacket/three jacket
- Mixer types: Impeller-type, Anchor-type, Turbine-type, High-shear-type, Magnetic mixer, Anchor-type mixer with scrapers,dispersing
- Optional: platform, wheels, ladder,variable frequency drive,explosion-proof device
- Certificates: ASME, CE, GMP, UL, ATEX, ISO 9001
- Our equipment supports customisation, global delivery, and a 1-year warranty.
- If you have drawings, we can process them for you.
Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909
$3,397.40 – $3,743.60Price range: $3,397.40 through $3,743.60
Guaranteed Safe Checkout

Recommend RPM: 0-960RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing

Recommend RPM: 0-200RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing

Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For single wall tank

Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For jacket tank

Recommend RPM: 1480/2850 RPM
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion

Recommend RPM: 2800 - 3200 RPM
Viscosity: Low/medium/High viscosity
Application: Liquid powder mixing and homogenizing

Recommend RPM: 0-355RPM
Viscosity: Low/medium viscosity
Application: Install at bottom, No mechanical seal working condition

Recommend RPM: As above
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion For tank volume >300L
Cosmetic Cream Mixing Tank for Vacuum Processing
We configure this vessel for cream and lotion batches that need controlled mixing, wall-surface turnover, and vacuum processing. A frame agitator with scraper blades helps move higher-viscosity product away from the vessel wall, where heating or cooling can otherwise create uneven conditions. A high-shear homogenizer can be specified to disperse oil and water phases or refine texture. Its position, power, and operating sequence depend on the formulation and target batch size; a homogenizer is not a substitute for a suitable sweep agitator in a thick product.
Construction and process options
Product-contact parts are commonly specified in 304 or 316L stainless steel. The choice depends on ingredients, cleaning chemicals, and corrosion risk. Internal welds should be continuous and finished to the agreed surface requirement, with hygienic design details confirmed for the intended cleaning method. Seal selection also matters: product chemistry, temperature, vacuum level, and cleaning routine affect elastomer compatibility and service life.
Heating or cooling may be arranged through a jacket or another engineered heat-transfer configuration. The required duty depends on batch volume, viscosity, temperature range, and processing time. Temperature sensors should reflect the actual process zone; a single reading may not show gradients in a viscous cream. Drive sizing likewise depends on product rheology and batch conditions. We select the gearbox, motor, scraper arrangement, and homogenizer after reviewing these details, rather than assuming one agitator design fits every formula.
Configuration details
| Item | Specification basis |
|---|---|
| Working capacity | Selected for batch size, headspace, and operating level |
| Vessel and contact surfaces | Stainless grade, weld finish, and polish set by product and cleaning needs |
| Mixing system | Frame scraper and optional high-shear homogenizer, sized to formulation |
| Vacuum and thermal service | Defined by process, temperature range, and plant utilities |
| Controls and discharge | Configured around operator workflow and downstream filling |
Applications and FAQs
Typical applications include cosmetic creams, lotions, gels, and personal-care emulsions. Can one vessel handle every product? Not necessarily; viscosity, solids, batch size, and cleaning change the required design. Is heating standard? It is a configuration choice based on the process. What should be included in a quotation request? Send batch volume, formula or ingredient properties, target temperatures, mixing time, vacuum requirements, cleaning method, utilities, and discharge or filling interface. These details let our engineers recommend a practical vessel and drive arrangement.
