Stainless Steel Mixing Tank with Bottom Emulsifier & Circulation Reactor
Stainless steel mixing tank with bottom emulsifier and circulation loop for pharmaceutical, food, and chemical batch processing. Configured for heating, cooling, vacuum or pressure, with sanitary welds and polish. Custom volumes available.
- Capacity: 50 liters to 30,000 liters
- Mixer power: 1.5 kW to 55 kW
- Material: [SUS304 / SUS316L]
- Voltage: 110V / 220V / 380V / 400V / 440V / 480V / 600V
- Heating method: [Electric / Steam / Thermal Oil / Hot Water / No Heating]
- Cooling method: [Cooling Jacket / Dimple Jacket / Coil / No Cooling]
- Agitation system: [Top Entry Agitator / Anchor Mixer / Paddle / Turbine / High-Shear Mixer / Customized]
- Optional features: [Insulation / Load Cells / Temperature Sensor / Pressure Gauge / Manhole / CIP / PLC Control / Explosion-Proof Motor]
- Certificates: ASME, CE, GMP, UL, ATEX, ISO 9001
- Working pressure: [Atmospheric / Positive Pressure / Vacuum / Specify pressure]
- If you have drawings, we can process them for you.
Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909
$3,684.46 – $4,761.80Price range: $3,684.46 through $4,761.80
Guaranteed Safe Checkout

Recommend RPM: 0-960RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing

Recommend RPM: 0-200RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing

Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For single wall tank

Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For jacket tank

Recommend RPM: 1480/2850 RPM
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion

Recommend RPM: 2800 - 3200 RPM
Viscosity: Low/medium/High viscosity
Application: Liquid powder mixing and homogenizing

Recommend RPM: 0-355RPM
Viscosity: Low/medium viscosity
Application: Install at bottom, No mechanical seal working condition

Recommend RPM: As above
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion For tank volume >300L
We build mixing and reaction vessels for production lines that cannot afford downtime. This stainless steel mixing tank integrates bottom emulsification, circulation conveying, and reaction heating into a single automated unit—engineered for batch consistency and repeatable processing.
The vessel is fabricated from 304 or 316L stainless steel, depending on your process media and cleaning requirements. Internal surfaces are mechanically polished to Ra ≤ 0.4 µm, with automatic orbital welding on all wetted seams. The bottom-mounted emulsifier handles high-shear dispersion, while the top-mounted agitator maintains bulk circulation. A side discharge loop allows continuous conveying, recirculation, or transfer downstream without breaking the sealed environment.
This reactor supports both heating and cooling jackets—steam, thermal oil, or chilled water—with a control valve skid for precise temperature ramping. The design pressure can be configured for atmospheric, positive pressure, or vacuum operation. Sealing options include single or double mechanical seals with flush plans, depending on solvent use and hygiene demands.
Typical Applications
- Pharmaceutical ointments, creams, and oral suspensions
- Food emulsions: sauces, dressings, recombined dairy
- Cosmetic lotions and gel manufacturing
- Chemical adhesives, coatings, and polymer dispersions
Technical Specifications
| Parameter | Available Configuration |
|---|---|
| Working Volume | 50 L – 20,000 L (custom) |
| Material | SS304 / SS316L, sanitary or industrial grade |
| Agitation | Anchor + bottom emulsifier + optional high-shear rotor |
| Heating/Cooling | Jacket with electric, steam, or thermal oil |
| Pressure | Atmospheric / positive / vacuum |
| Seal Type | Single or double mechanical seal |
| Surface Finish | Ra 0.4–0.8 µm internal, brushed external |
Selection Checklist
Before requesting a quote, confirm these process details: the chemical composition and concentration of your materials, batch size, operating and design temperature, pressure or vacuum requirements, viscosity range, and whether your process needs CIP or manual cleaning. Also specify if you require explosion-proof motors or a specific control automation level.
FAQ
Q: Can I use this tank for both mixing and reaction?
Yes, the vessel is designed for combined heat transfer, mixing, and emulsification in one unit.
Q: What determines whether I need 304 or 316L?
316L is recommended for chloride-containing products or aggressive cleaning agents. For neutral or low-corrosion media, 304 is sufficient.
Q: How is cleaning handled?
We offer spray balls for CIP, and the emulsifier housing is designed to drain cleanly with no dead zones.
Send us your material composition, batch volume, temperature, pressure, and mixing requirements. We will respond with a recommended configuration and factory pricing.
