High Shear Emulsifier Mixer Homogenizer for Food/Sauce/Paint/Cosmetic Lotion

Batch High Shear Mixing, Built Around Your Process

We build this batch high shear mixer for plants that need one machine to handle sauce bases, paint dispersions, cosmetic lotions, and similar products without pretending every formulation behaves the same. The unit combines high-speed shear, dispersion, and emulsification, and it helps break down powders into liquids when the mixing head and tank arrangement suit the job.

Because batch high shear mixing equipment is rarely a catalog-only purchase, we configure the drive, shaft, head, and contact materials around your vessel, product viscosity, and target turn-down ratio. A high shear mixer with VFD control lets operators adjust from 0 to 3000 rpm depending on motor and configuration, which matters when a single sku runs thin lotions and heavier pastes.

Configurable Specifications

• Motor power: 1.5 kW to 55 kW, matched to batch size and product resistance.
• Voltage: 220V to 480V; frequency, phase, and electrical arrangement confirmed for the destination market.
• Speed control: optional VFD for 0–3000 rpm adjustment, depending on selected motor and configuration.
• Contact materials: 304 or 316L stainless steel, specified where wetted parts and product chemistry require it.
• Mixing functions: high shear, dispersion, emulsification, and powder incorporation into liquids.
• Mounting: fixed or mobile high shear mixer arrangement, depending on tank layout and changeover practice.

What to Confirm Before Selecting a Unit

Start with batch size and vessel dimensions, including working volume and headspace. Product viscosity and solids loading decide whether a high shear mixer for powder dispersion will actually wet out powders or just move them around. Required mixing speed and motor power should come from the process, not a guess. Electrical supply—voltage, frequency, and phase—must be known before we finalize the drive package. Mixing head design and contact parts need to match the product; 316L is common for more aggressive formulas, while 304 covers many food and cosmetic duties. Mobile versus fixed mounting depends on how often the tank or product changes.

Applications

Industrial high shear mixers from Ace Mixer are used in food and beverage processing, cosmetics and personal care, pharmaceutical and healthcare preparations, chemical processing, and paints and coatings. They also handle powder dispersion and liquid–liquid emulsification where the formulation allows. Suitable head style, material, and operating parameters depend on viscosity, composition, and process requirements—not on a generic “all-purpose” claim.

FAQ

Can one unit handle both thin lotion and thick sauce? Sometimes, but the motor, shaft, and head need to be sized for the heavier condition. A variable speed high shear mixer with VFD helps, yet it does not replace proper mechanical sizing.

Do you supply sanitary or explosion-proof versions? We confirm electrical and material requirements per project. Certifications and specific compliance needs should be stated in the inquiry so we can discuss what is available for that configuration.

How do we choose between mobile and fixed mounting? Use mobile when tanks are swapped frequently or floor space is tight. Fixed mounting suits dedicated vessels and shorter transfer runs.

What information speeds up a quote? Batch size, product viscosity and composition, target rpm, required motor power, contact material preference, and local voltage/frequency/phase.

Send those details to Ace Mixer, and we will recommend a stainless steel high shear mixer configuration for your line—without oversizing the drive or undersizing the shaft.
