25000L SS304 Food Grade Water Storage Tank for Drinking, Process & Industrial Use

Custom 25,000L SS304 water storage tank for drinking, process water, and food beverage applications. Food-grade polished interior, atmospheric design, and full customization available from an experienced stainless steel fabricator.

Tank Capacity: [50L–100,000L or specify actual capacity]
Tank Type: [Vertical / Horizontal / Single-wall / Double-wall / Jacketed]
Material: 304 or 316L
Optional Features: [Insulation / Heating / Cooling / Agitator / Level Gauge / Manway / CIP Spray Ball / Load Cells / Wheels / Custom Connections]
Surface Finish: [2B / Brushed / Polished / Mirror Polish]
If you have drawings, we can process them for you.

Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909

Price range: $2,580.58 through $3,235.02

Ask For A Quotation

Guaranteed Safe Checkout

25000L SS304 Food Grade Water Storage Tank

This 25,000-liter vertical storage tank is built for facilities that need dependable potable water or process water storage without the risk of contamination. We fabricate it from SS304 sheet metal, with a food-grade interior finish that stands up to repeated cleaning cycles.

The shell is rolled from single sheets and welded with full-penetration TIG welds on the inside and outside. We grind the internal weld seams flush and then mechanically polish the interior to a 0.4–0.8 μm Ra finish. That matters when you are storing drinking water or product-contact process water because rough surfaces harbor biofilm. The exterior receives a 180–320 grit brushed finish, which is practical for industrial environments—easy to clean and less prone to visible fingerprints.

Standard construction includes a dished top and flat cone bottom with a center outlet. We reinforce the bottom with radial stiffeners to prevent sagging under full hydrostatic load. The tank includes a 20-inch manhole at the side for internal access, a pressure/vacuum vent at the top, and a side-mounted level indicator. All connections are tri-clamp or flanged, depending on your piping setup.

This is a non-pressure, atmospheric vessel. If your process requires pressure or vacuum duty, we need to know that before quoting—it changes the plate thickness, head design, and weld inspection requirements.

Typical Applications

Drinking water storage for food plants and municipal auxiliary systems
Process water buffering in beverage, dairy, and sauce production lines
Cleaning water supply for CIP systems
Raw water holding for industrial cooling or treatment systems

Material & Finish Options

SS304 is the right choice for neutral pH water and most food products. If you are storing chlorinated water above 10 ppm, acidic liquids, or brine, we recommend SS316L instead. We can also supply a rougher internal finish (0.8–1.2 μm Ra) if your process does not require high hygiene, which reduces cost.

Technical Specifications

Capacity	25,000 L (usable volume approx. 24,000 L)
Material	SS304 (1.4301), 4 mm shell, 5 mm bottom
Design	Atmospheric, vertical, dished top, cone bottom
Surface	Internal 0.4–0.8 μm Ra, external brushed
Connections	Tri-clamp or flanged, custom layout
Accessories	Manhole, vent, level gauge, leg supports

Customization

We can add an insulation jacket with cladding, electric or steam heating coils, an agitator bracket, or extra nozzles for recirculation. Tell us your pipe sizes and connection types. We weld all fittings before final polishing so there are no dead zones.

We ship these tanks knocked down or fully assembled, depending on your site access. For overseas projects, we provide lifting lugs and wooden crates with steel frames.
