Stainless Steel Crystallization Reactor with Agitator & Conical Bottom for Salt, Sugar & Chemical Processing
Industrial stainless steel crystallization reactor with conical bottom and agitator motor, built for salt, sugar, and chemical processing. Customizable jacket, seal, and mixing options for reliable batch crystallization.
- Capacity: 50 liters to 30,000 liters
- Mixer power: 1.5 kW to 55 kW
- Material: [SUS304 / SUS316L]
- Voltage: 110V / 220V / 380V / 400V / 440V / 480V / 600V
- Heating method: [Electric / Steam / Thermal Oil / Hot Water / No Heating]
- Cooling method: [Cooling Jacket / Dimple Jacket / Coil / No Cooling]
- Agitation system: [Top Entry Agitator / Anchor Mixer / Paddle / Turbine / High-Shear Mixer / Customized]
- Optional features: [Insulation / Load Cells / Temperature Sensor / Pressure Gauge / Manhole / CIP / PLC Control / Explosion-Proof Motor]
- Certificates: ASME, CE, GMP, UL, ATEX, ISO 9001
- Working pressure: [Atmospheric / Positive Pressure / Vacuum / Specify pressure]
- If you have drawings, we can process them for you.
Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909
$3,573.14 – $4,492.51Price range: $3,573.14 through $4,492.51
Guaranteed Safe Checkout

Recommend RPM: 0-960RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing

Recommend RPM: 0-200RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing

Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For single wall tank

Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For jacket tank

Recommend RPM: 1480/2850 RPM
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion

Recommend RPM: 2800 - 3200 RPM
Viscosity: Low/medium/High viscosity
Application: Liquid powder mixing and homogenizing

Recommend RPM: 0-355RPM
Viscosity: Low/medium viscosity
Application: Install at bottom, No mechanical seal working condition

Recommend RPM: As above
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion For tank volume >300L
We build crystallization reactors for processes where controlled cooling, gentle agitation, and reliable solids handling matter. This unit is designed around the realities of salt, sugar, and chemical crystallization — where product consistency depends on uniform heat transfer and steady mixing.
The reactor uses a conical bottom to promote complete discharge of crystal slurries. Flat-bottom tanks leave heel buildup and force operators to open manways for cleaning. The cone angle is matched to the expected flow characteristics of your slurry, so you get gravity-assisted drainage without dead zones.
Material selection is straightforward but not simplistic. Standard build uses 304 or 316L stainless steel, depending on chloride exposure and product contact requirements. We weld with full penetration and follow up with mechanical polishing — internal surfaces typically finished to Ra ≤ 0.6 µm where cleaning and product release are critical. External surfaces get a brushed finish for plant hygiene.
The agitator motor and drive assembly are sized for your specific viscosity and solids loading, not guessed. We offer anchor, helical ribbon, or combination impellers. For crystallization duty, low shear is often more important than high speed. If your process requires it, we can fit a variable frequency drive for precise speed control during seeding and growth phases.
Heating and cooling jackets are designed to match your thermal duty. Options include single jacket, half-pipe coil, or dimple jackets — each with different pressure and heat transfer characteristics. We need your process temperatures and heating/cooling media to recommend the right configuration.
Sealing matters. We supply mechanical seals or magnetic drives depending on whether you need zero emission containment. For vacuum operation, the seal selection and shaft support become critical — we address that at the engineering stage, not as an afterthought.
Technical Specifications
| Capacity | Custom, typically 500L – 30,000L |
| Material | SS304, SS316L, or dual-grade |
| Internal finish | Ra ≤ 0.4 – 0.8 µm (mirror or satin) |
| Jacket type | Single, half-pipe, or dimple |
| Agitator | Anchor, ribbon, turbine, or custom |
| Seal | Mechanical or magnetic drive |
| Design pressure | Full vacuum to 10 bar (custom) |
| Temperature range | Dependent on gasket and jacket spec |
Before You Request a Quote
To size the reactor correctly, we need more than a tank volume. Tell us:
- The chemical composition and concentration of your process stream
- Batch volume and working volume
- Operating and design temperature
- Pressure — atmospheric, pressurized, or vacuum
- Viscosity and solids content of the slurry
- Whether you need heating, cooling, or both
- Required mixing intensity and any shear limits
- Cleaning method (CIP) and any compliance standards
Send us those details. We will recommend the vessel configuration, agitator type, jacket design, and seal arrangement that fits your process — then provide a quotation based on engineering, not guesswork.
