Mobile Lift Homogenizer Mixer for Cosmetics and Food

A mobile lift-mounted mixer for liquid, lotion, and similar batches requiring blending, dispersion, or homogenization. Mixing head, motor, lift arrangement, wetted materials, and optional temperature-control provisions are selected around the formulation, vessel, cleaning procedure, and production target. Share batch and process details to determine a suitable configuration.

Capacity: 50 liters to 30,000 liters
Mixer power: 1.5 kW to 55 kW
Material: 304 or 316L
Voltage: 110V to 600V
Heating method: Electric or steam heating
Layer:single/double jacket/three jacket
Mixer types: Impeller-type, Anchor-type, Turbine-type, High-shear-type, Magnetic mixer, Anchor-type mixer with scrapers,dispersing
Optional: platform, wheels, ladder,variable frequency drive,explosion-proof device
Certificates: ASME, CE, GMP, UL, ATEX, ISO 9001
Our equipment supports customisation, global delivery, and a 1-year warranty.
If you have drawings, we can process them for you.

Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909

Price range: $8,921.75 through $10,225.22

Ask For A Quotation

Guaranteed Safe Checkout

Designed around the batch and vessel

This mobile lift-mounted mixer is intended for liquid and lotion batches that need dispersion, blending, or homogenization. The right setup depends on more than batch volume: viscosity, powder addition, required particle reduction, vessel diameter, and cleaning method all affect the working head and drive selection. We confirm whether the process calls for a high-speed dispersing blade, a rotor-stator homogenizing head, a separate agitator, or a combination. These tools are not interchangeable; using the wrong one can leave unmixed zones or introduce unwanted air.

Construction and configuration

Product-contact parts can be specified in an appropriate stainless steel grade, commonly 304 or 316L when the formulation or cleaning chemistry requires greater corrosion resistance. The choice should follow ingredient compatibility, washdown practices, and applicable plant standards. Welds, corners, and shaft details should be designed for the cleaning method; sanitary polishing requirements can be specified where product contact calls for them. Seal material also needs to suit the formulation, temperature, and cleaning agents.

The lift may use a pneumatic or electric arrangement, subject to the required travel, mixer head weight, available utilities, and site safety requirements. Motor and gearbox selection depends on viscosity, batch size, tool diameter, and operating speed. A variable-speed drive may help manage startup and process changes, but the usable speed range must match the selected impeller. Heating is not assumed as standard: when temperature control is needed, a jacketed vessel or external heating system, sensor location, and control range should be defined with the process.

Configuration data

Item	Specification basis
Batch capacity	Set by vessel dimensions and working volume
Wetted materials	Selected for product and cleaning compatibility
Lift and drive	Pneumatic or electric lift; motor and speed configured to process
Heating and controls	Optional, defined by temperature and control requirements
Mixing tool	Selected for dispersion, homogenization, or blending duty

Applications and common questions

Typical uses include cosmetic lotions and creams, food sauces, and liquid products requiring controlled powder incorporation. Can one machine serve several products? Often, but viscosity range, cleaning changeovers, and tool exchange need review. Is a stated tank capacity enough to size the mixer? No; provide working volume, vessel dimensions, and batch behavior.

Prepare for a quotation

Send the formulation type, batch size, viscosity or a representative sample, target process result, vessel dimensions, temperature range, cleaning procedure, available power or compressed air, and installation constraints. These details let our engineers recommend a workable lift, drive, mixing head, and materials configuration instead of sizing from volume alone.
