A 500L stainless steel vacuum mixing tank with top-mounted agitator motor and square steel frame. Designed for chemical, pharmaceutical, and food processing where vacuum operation, uniform blending, and stable support are required. Customizable in 304 or 316L.

Capacity: 50 liters to 30,000 liters
Mixer power: 1.5 kW to 55 kW
Material: [SUS304 / SUS316L]
Voltage: 110V / 220V / 380V / 400V / 440V / 480V / 600V
Heating method: [Electric / Steam / Thermal Oil / Hot Water / No Heating]
Cooling method: [Cooling Jacket / Dimple Jacket / Coil / No Cooling]
Agitation system: [Top Entry Agitator / Anchor Mixer / Paddle / Turbine / High-Shear Mixer / Customized]
Optional features: [Insulation / Load Cells / Temperature Sensor / Pressure Gauge / Manhole / CIP / PLC Control / Explosion-Proof Motor]
Certificates: ASME, CE, GMP, UL, ATEX, ISO 9001
Working pressure: [Atmospheric / Positive Pressure / Vacuum / Specify pressure]
If you have drawings, we can process them for you.

Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:[email protected]
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909

Price range: $3,966.59 through $4,855.90

Ask For A Quotation

Guaranteed Safe Checkout

500L Vacuum Mixing Tank with Agitator and Motor

We build this 500L mixing tank for processors who need reliable vacuum operation, uniform agitation, and a rigid support structure in one unit. The square steel frame keeps the vessel stable during high-viscosity mixing, while the top-mounted motor and agitator handle batch work without excessive floor footprint.

The wetted parts are fabricated from stainless steel with full penetration welds and a smooth interior finish. We offer 304 or 316L depending on your product chemistry. Internal surfaces are polished to reduce product adhesion and make cleaning between batches straightforward. For processes requiring sterile conditions, we can increase the surface finish specification and add sanitary tri-clamp connections.

The vacuum-capable design allows you to deaerate pastes, prevent oxidation of sensitive compounds, or draw powders into the liquid phase. Heating and cooling options include a jacket or half-pipe coil with your choice of thermal fluid, steam, or chilled water. Working pressure, design temperature, and agitator type are matched to your process after we review your requirements.

Typical applications include chemical blending, pharmaceutical intermediates, food sauces and dressings, cosmetic creams, and adhesive production. We can adjust the impeller style, baffle arrangement, and motor power to suit viscosity and solids content.

Technical Specifications

Capacity: 500L (working volume configurable)
Frame: Square steel frame with adjustable feet
Agitator: Top-mounted motor with gearbox
Sealing: Mechanical seal or stuffing box
Finish: Internal mirror polish optional
Options: CIP spray ball, sight glass, pressure gauge, sampling valve

FAQ

What is the maximum operating temperature?
It depends on the gasket and seal material selected. For standard PTFE and EPDM components, 150°C is a common limit; higher requires custom selection.

Can this tank handle vacuum up to -0.09 MPa?
Yes, but we need to confirm the vessel design and seal type based on your required vacuum level.

How do I choose between 304 and 316L?
If you process chlorides, acids, or pharmaceutical products, 316L is usually safer. For general water-based mixing, 304 is cost-effective.

Do you provide drawings before production?
Yes, we send dimensional drawings and P&ID for your approval before fabrication.

Procurement Guidance

Before requesting a quote, prepare the following: the exact material being mixed, its chemical composition and concentration, batch size and working volume, operating and design temperature, pressure or vacuum range, viscosity and solid content, and whether heating or cooling is needed. Also note the required mixing result and any cleaning or compliance standards.

Email us with these details so our engineers can recommend the right configuration, impeller type, seal arrangement, and frame design. We will provide a technical proposal and quotation based on your actual process conditions.
