20L 316L Stainless Steel Mayonnaise and Salad Dressing Emulsifier Mixer
A 20L SUS316L stainless steel mixer for mayonnaise, salad dressing, and other viscous food batches. Mixing geometry, drive power, seals, surface finish, and optional temperature control should be matched to the formulation, batch volume, and cleaning process. Share your recipe details and production targets to help determine a suitable configuration.
- Capacity: 50 liters to 30,000 liters
- Mixer power: 1.5 kW to 55 kW
- Material: 304 or 316L
- Voltage: 110V to 600V
- Heating method: Electric or steam heating
- Layer:single/double jacket/three jacket
- Mixer types: Impeller-type, Anchor-type, Turbine-type, High-shear-type, Magnetic mixer, Anchor-type mixer with scrapers,dispersing
- Optional: platform, wheels, ladder,variable frequency drive,explosion-proof device
- Certificates: ASME, CE, GMP, UL, ATEX, ISO 9001
- Our equipment supports customisation, global delivery, and a 1-year warranty.
- If you have drawings, we can process them for you.
Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909
$8,240.68 – $9,228.74Price range: $8,240.68 through $9,228.74
Guaranteed Safe Checkout

Recommend RPM: 0-960RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing

Recommend RPM: 0-200RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing

Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For single wall tank

Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For jacket tank

Recommend RPM: 1480/2850 RPM
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion

Recommend RPM: 2800 - 3200 RPM
Viscosity: Low/medium/High viscosity
Application: Liquid powder mixing and homogenizing

Recommend RPM: 0-355RPM
Viscosity: Low/medium viscosity
Application: Install at bottom, No mechanical seal working condition

Recommend RPM: As above
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion For tank volume >300L
20L Mayonnaise and Salad Dressing Mixer
This 20L mixer is intended for small-batch development, pilot production, or specialty food runs involving viscous, oil-and-water products. Mayonnaise and dressings can be difficult to process: oil addition rate, ingredient temperature, batch size, and mixing sequence all affect emulsion formation and final texture. We configure the mixing system around the recipe and required output rather than assuming one impeller will suit every formulation.
Materials and hygienic construction
The product-contact material is specified as SUS316L stainless steel. We confirm the wetted-part scope, gasket material, surface finish, and cleaning method during design review. Welds and internal transitions should be finished to suit the plant’s sanitation requirements, with crevices and residue traps minimized. Seal selection depends on the ingredients, operating temperature, cleaning chemicals, and whether the process requires frequent disassembly. The frame and non-contact components may use different materials, subject to the installation environment and customer specification.
Mixing and process options
Drive power, speed range, and mixer geometry depend on viscosity, batch fill level, and the desired shear. A high-shear emulsifying head may help disperse oil droplets, while a slower sweep or anchor-style agitator can improve circulation in thicker formulations. These functions may require different configurations; specifying a machine from product name alone can lead to poor turnover or unnecessary shear. Heating is not confirmed as standard. If the recipe needs temperature control, we can review a jacket or other heating arrangement, temperature range, heat-up time, and control method as part of the quotation.
Technical specification
| Item | Available information |
|---|---|
| Application | Mayonnaise, salad dressing, and viscous food mixing |
| stated capacity | 20 L; confirm working volume and batch basis |
| Product-contact material | SUS316L stainless steel |
| Motor, speed, heating, finish, seals | Confirm to process and site requirements |
FAQ
Can it handle a thick recipe? We need the viscosity or a representative sample, batch size, and target mixing time to assess the drive and agitator.
Is 20 L the usable batch volume? The listed capacity is 20 L. Confirm working volume, headspace, and loading method before ordering.
What should a quote request include? Send the recipe or ingredient list, batch volume, oil addition method, target texture, temperature profile, cleaning procedure, power supply, and any applicable food-safety requirements. These details let our engineers recommend a practical configuration.
