100L Industrial Mixing Tank for Ink, Cosmetics, Food and Paint
100L Industrial Mixing Tank for Ink, Cosmetics, Food and Paint Price range: $2,476.77 through $2,772.00

100L Electric Heated Liquid Glucose Syrup Mixing Machine

The 100L electric heated liquid glucose syrup mixing machine is designed for controlled warming and agitation of viscous syrups. Configuration details such as stainless steel grade, impeller style, drive torque, heating arrangement, temperature control, seals, and discharge design are selected according to viscosity, batch volume, sanitation requirements, cleaning method, and plant utilities.

Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909

Price range: $2,509.08 through $2,784.33

Ask For A Quotation​

Guaranteed Safe Checkout

Optional agitator
Propeller mixer

Recommend RPM: 0-960RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing

Paddle mixer

Recommend RPM: 0-200RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing

Anchor Agitator

Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For single wall tank

Scraper agitator

Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For jacket tank

Dispersion mixer

Recommend RPM: 1480/2850 RPM
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion

Homogenizer

Recommend RPM: 2800 - 3200 RPM
Viscosity: Low/medium/High viscosity
Application: Liquid powder mixing and homogenizing

Magnetic mixer
Magnetic mixer

Recommend RPM: 0-355RPM
Viscosity: Low/medium viscosity
Application: Install at bottom, No mechanical seal working condition

Anchor & Homogenizer combine

Recommend RPM: As above
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion For tank volume >300L

Product description

100L Electric Heated Liquid Glucose Syrup Mixing Machine

Glucose syrup processing often becomes difficult when viscosity rises during heating. Cold spots, localized scorching, and incomplete blending can affect batch consistency and increase cleaning time. We build this 100-liter electric heated mixing machine for controlled warming and agitation of liquid glucose syrup, with the working arrangement adjusted to the product, batch schedule, and plant utilities.

Construction and Process Considerations

Product-contact parts are commonly specified in stainless steel, with the grade selected according to syrup composition, cleaning chemicals, temperature, and sanitation requirements. Welds should be continuous where product can collect, then ground and polished to the required finish. Internal corners, outlet geometry, cover design, and gasket material all affect drainage and washdown performance. For food or pharmaceutical service, we review surface finish, elastomer compatibility, inspection access, and documentation before fabrication.

Electric heating can be arranged through a jacket or another engineered heat-transfer configuration, depending on the required temperature range and heat-up time. A properly sized temperature sensor and controller help prevent overheating at the vessel wall. Glucose syrup usually needs steady, moderate agitation rather than unnecessarily high shear; the impeller, shaft, motor, and gearbox are selected according to viscosity, fill level, solids content, and desired mixing time. Higher torque may be required during cold starts.

Typical Applications

This equipment is used in confectionery syrup preparation, bakery fillings, beverage bases, dessert toppings, pharmaceutical liquids, and selected cosmetic formulations. A candy producer may use it to maintain syrup flow before transfer, while a food plant may use the vessel for dissolving and blending ingredients before a downstream cooking or filling step.

Technical Specifications

Item Available information
Nominal capacity 100 liters
Heating method Electric heating
Product Liquid glucose syrup and related formulations
Agitation system Impeller, drive, and speed selected by process requirements
Material and finish Specified according to product, sanitation, and cleaning method

Procurement Questions

Capacity alone does not determine the correct configuration. Send the target batch volume, syrup viscosity at operating and starting temperatures, heating setpoint, heat-up time, ingredient loading sequence, mixing time, cleaning method, discharge arrangement, available power, and required sanitary standards. We then size the heater and drive, confirm vessel geometry, and recommend suitable materials, seals, controls, and access features. This information prevents a common purchasing error: selecting a nominal 100-liter vessel without checking usable working volume, torque demand, or the actual heating duty.
