Sanitary High Shear Mixer Emulsifier Pump for Chocolate & Liquid Soap
- Material: 304 or 316L
- Voltage: 110V 208V 220V 380V 400V 415V 480V 600V
- Certificates: CE, GMP, UL, ATEX, ISO 9001
- Power：0.75KW-55KW （1 HP – 74 HP）
- Motor brands: ABB, Chinese brands, SEW, Siemens (optional)
- 1-year free warranty with door-to-door delivery.
- Optional: Variable-frequency drive, control panel
- MADE IN CHINA
- We have it in stock.
Please contact our sales team before placing your order.
Email:info@ace-chn.com
Tel:+86 18626835909
WeChat: ace-chn
Price range: $1,994.67 through $2,115.95
Guaranteed Safe Checkout
We manufacture and sell the following types of mixers
Mix, emulsify, homogenize, disintegrate and dissolve
Ideal for disintegrating solids and incorporating powders
Reduce mixing times by up to 80%
Reduce mixing times by up to 90%
Quickly disperse and hydrate powders, even at higher viscosities
Easy to move and lift
Features heating, cooling, vacuum, and other functions
Recommended RPM: 1480/2850 RPM
In-Line High Shear Mixing for Chocolate, Liquid Soap, and Cosmetic Emulsions
This Ace Mixer unit is built around a high-speed rotor-stator head mounted in a sanitary pump housing. Product enters the mixing chamber, passes through close rotor/stator slots, and exits as a more uniform stream. In a continuous line or tank recirculation loop, that repeated shear does the work a batch agitator often cannot reach: breaking down powders, wetting thickeners, and tightening oil-water emulsions before they set.
For chocolate and compound coatings, the head helps disperse cocoa powder, sugar, and milk solids and reduce visible agglomerates. For liquid soap, shampoo, and lotion bases, it provides repeated mechanical shear as the product circulates, which can shorten the time needed to reach a consistent appearance and viscosity. Results depend on solids loading, viscosity, temperature, and the number of passes, so we size the rotor, motor, and seal to the actual duty rather than a single model number.
Practical benefits on the production floor
- Inline mounting fits into existing pipework, recirculation tanks, or transfer skids, with less floor space than another batch vessel.
- Sanitary 316L stainless steel wetted parts and food-grade elastomer options suit food, cosmetic, and pharmaceutical washdown areas.
- Rotor-stator shear supports emulsification, powder dispersion, and de-agglomeration in one pass-through device.
- VFD options let operators tune tip speed for light lotions versus viscous soap or chocolate masses.
- Custom motor power, connections, mechanical seals, and contact materials are available for specific plant standards.
High-viscosity service deserves an honest review. Above certain limits, the pump may need a separate feed pump, larger motor, or heated jacket. We ask for viscosity range, solids content, temperature, batch size, and target particle size before recommending a configuration.
Applications
Food and beverage: sauces, dressings, syrups, dairy blends, starch and gum dispersions. Cosmetics and personal care: creams, lotions, conditioners, liquid detergents. Pharmaceutical: suitable liquid formulations and excipient dispersions where materials and seals match the process. Chemical: compatible water-based emulsions, coatings, and adhesives. One pump configuration will not handle every formula.
FAQ
Can it run inline with my existing tank? Yes, if piping, flow rate, and net positive suction head are checked. Recirculation is common.
Do I need a VFD? It helps when products change viscosity or when shear needs adjustment. Fixed speed is possible.
What about sanitation? We review elastomers, seal flush, surface finish, and cleaning practice with your team.
Send batch size, product viscosity, solids, required motor power, connection standard, and local voltage to Ace Mixer for a practical configuration and quote.
Ace Mixer sanitary inline high shear mixer emulsifier pump for chocolate, liquid soap, cosmetics, food, and chemical processing. The rotor-stator head supports powder dispersion, emulsification, and de-agglomeration in continuous or recirculation systems. Stainless steel construction, VFD and seal options, and custom connections are available. Share viscosity, batch size, solids, motor power, and voltage for a proper configuration and quote.
Single-stage in-line mixer
Three-stage in-line mixer
High-Shear Mixer with lift
High shear mixer
