Vacuum Emulsifying Mixer for Cosmetics with Mixing Tank and Homogenizer
A configurable vacuum emulsifying mixer for cosmetic creams, lotions, gels, and related products. The system combines a mixing vessel, bulk agitator, and homogenizer, with material, seal, heating, finish, and control options selected for the formula and cleaning process. Share batch size, viscosity, temperature profile, vacuum requirements, and available utilities to establish a suitable configuration and request a project-specific quotation.
- Capacity: 50 liters to 30,000 liters
- Mixer power: 1.5 kW to 55 kW
- Material: [SUS304 / SUS316L]
- Voltage: 110V / 220V / 380V / 400V / 440V / 480V / 600V
- Heating method: [Electric / Steam / Thermal Oil / Hot Water / No Heating]
- Cooling method: [Cooling Jacket / Dimple Jacket / Coil / No Cooling]
- Agitation system: [Top Entry Agitator / Anchor Mixer / Paddle / Turbine / High-Shear Mixer / Customized]
- Optional features: [Insulation / Load Cells / Temperature Sensor / Pressure Gauge / Manhole / CIP / PLC Control / Explosion-Proof Motor]
- Certificates: ASME, CE, GMP, UL, ATEX, ISO 9001
- Working pressure: [Atmospheric / Positive Pressure / Vacuum / Specify pressure]
- If you have drawings, we can process them for you.
Note: Please contact our sales team before placing an order. Website prices are for reference only; specific pricing requires understanding your requirements to provide a quote.
Email:info@ace-chn.com
Tel: +86 186 2683 5909
WeChat: ace-chn
WhatsApp: +86 186 2683 5909
Price range: $2,555.40 through $2,907.02
Guaranteed Safe Checkout
Recommend RPM: 0-960RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing
Recommend RPM: 0-200RPM
Viscosity: Low/medium viscosity
Application: Mainly Liquid mixing
Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For single wall tank
Recommend RPM: 30RPM
Viscosity: Medium/High viscosity
Application: Melting, High viscosity product mixing, For jacket tank
Recommend RPM: 1480/2850 RPM
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion
Recommend RPM: 2800 - 3200 RPM
Viscosity: Low/medium/High viscosity
Application: Liquid powder mixing and homogenizing
Recommend RPM: 0-355RPM
Viscosity: Low/medium viscosity
Application: Install at bottom, No mechanical seal working condition
Recommend RPM: As above
Viscosity: Low/medium viscosity
Application: Liquid powder mixing and dispersion For tank volume >300L
Vacuum Emulsifying Mixer for Cosmetic Production
We configure vacuum emulsifying systems around the batch recipe, product viscosity, and cleaning method—not just tank volume. Vacuum processing can help limit entrained air while the agitator and homogenizer work to disperse oils, powders, and other ingredients into a consistent emulsion. This equipment is commonly specified for creams, lotions, gels, and similar personal-care products. The required shear and mixing sequence depend on the formulation; a high-speed homogenizer does not replace the need for suitable bulk circulation.
Construction and configuration
Product-contact parts are commonly fabricated from 304 or 316L stainless steel. The appropriate grade depends on ingredients, cleaning chemicals, and corrosion exposure. Welds, internal corners, and outlet geometry should be reviewed for cleanability. Internal surfaces can be mechanically polished to a finish agreed for the process; a specific finish value should be defined in the purchase specification rather than assumed. Seal materials are selected for product compatibility, operating temperature, and vacuum conditions.
Agitator style, scraper arrangement, homogenizer position, and drive sizing are determined by batch size and rheology. Scrapers can improve heat transfer and reduce product buildup on the vessel wall, but their materials and clearances must suit the formulation. Motor and gearbox selection accounts for viscosity, starting load, speed range, and duty cycle. Heating may use an insulated jacket with a customer-selected utility or electric arrangement. Cooling, temperature sensors, and control logic can be configured to match the batch process; heating capacity and temperature range require project-specific confirmation.
Configuration data
| Item | Specification basis |
|---|---|
| Working capacity | Selected from batch size and usable fill level |
| Contact material | 304 or 316L stainless steel, subject to product compatibility |
| Mixing system | Agitator and homogenizer configured for recipe and viscosity |
| Heating and cooling | Defined by utility availability and process temperature profile |
| Controls and finish | Specified to cleaning, operation, and site requirements |
Frequently asked questions
Can one machine handle several formulas? Often, but viscosity range, batch size, shear sensitivity, and cleaning changeover need review before sizing.
What should be confirmed before fabrication? Provide batch volume, ingredient sequence, target temperatures, vacuum needs, product viscosity, cleaning procedure, available utilities, and installation constraints. These details let our engineers recommend a practical configuration and identify tradeoffs before quoting.
